Fujitsu PRIMERGY RX2540 M2

422 Upgrade and Maintenance Manual RX2540 M2
Accessible drives
12.3.2.2 Removing the ODD
Figure 305: Removing the cables from the ODD
Ê Disconnect the SATA cable C3 and the power cable C5.
Figure 306: Removing the ODD
Ê Unlock the ODD latch.
C3
C5
