530 Upgrade and Maintenance Manual RX2540 M2
System board and components
Ê Save your changes and exit the BIOS.
Ê "Switching on the server" on page 82
Ê "Resuming BitLocker functionality" on page 120
14.4.2 Removing the TPM
V CAUTION!
Advise your contact persons that they must provide you with TPM
backup copies. For security reasons, the TPM must be restored/re-
saved by the customer. After installing a new system board, the TPM
must be enabled. You may not clear the TPM data.
If the contact persons DO NOT have a backup copy available, inform
them that replacing the TPM will cause to lose all data.
Upgrade and Repair Unit
(URU)
Hardware: 30 minutes
Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver / nut driver 5 mm
Removing the TPM:
– flat nose pliers
– thin slotted screw driver (2 x 0.4 mm) *
(
*
)
For the Japanese market:
– Dedicated TPM screw driver (CWZ8291A)
