RX2540 M2 Upgrade and Maintenance Manual 325
Expansion cards and backup units
8.7.4.2 Removing an FBU from the air duct
Ê "Removing the FBU holder from the air duct" on page 322
8.7.4.3 Disconnecting the FBU adapter cable from the FBU
Figure 220: Disconnecting the FBU adapter cable
Ê Press down on the locking latch on the FBU cable and disconnect the FBU
adapter cable.
