492 Upgrade and Maintenance Manual RX2540 M2
Front panel and external front connectors
Ê Store your server’s system information on the Chassis ID EPROM
integrated into the front panel board. For further information on how to obtain
and use the ChassisId_Prom Tool, refer to section "Using the Chassis ID
Prom Tool" on page 123.
Ê "Enabling SVOM boot watchdog functionality" on page 114
Ê "Resuming BitLocker functionality" on page 120
13.7 Front VGA connector 2.5-inch versions
13.7.1 Installing the front VGA connector
13.7.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 95
Ê "Locating the defective server" on page 61
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
13.7.1.2 Removing the front panel module
Ê "Removing the front panel cage" on page 479
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: flat screw driver
Phillips PH1 / (+) No. 1screw driver
Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
