Fujitsu PRIMERGY RX2540 M2

RX2540 M2 Upgrade and Maintenance Manual 195
Hard disk drives (HDD) and solid state drives (SSD)
7.4.2.3 Installing a 2.5-inch HDD/SSD module
Figure 95: Unlocking a 2.5-inch HDD/SSD module
Ê Pinch the green locking clip (1) and open the locking lever (2).
