190 Upgrade and Maintenance Manual RX2540 M2
Hard disk drives (HDD) and solid state drives (SSD)
7.4.1.3 HDD mounting order for 24x 2.5-inch HDD/SSD configuration
Figure 91: 24x 2.5-inch HDD/SSD mounting order
I The HDD/SSD numbering as listed in the ServerView RAID Manager
differs from the HDD mounting order:
[15] 14 Vendor Product (14) Vendor Product (1:6)
[16] 15 Vendor Product (15) Vendor Product (1:7)
Mounting order
Position
Position
Logical drive
number
ServerView RAID Manager display name
(Enclosure number: Port number)
one SAS controller and SAS expander board
[1] 0 Vendor Product (1:0)
[2] 1 Vendor Product (1:1)
[3] 2 Vendor Product (1:2)
[4] 3 Vendor Product (1:3)
[5] 4 Vendor Product (1:4)
[6] 5 Vendor Product (1:5)
[7] 6 Vendor Product (1:6)
[8] 7 Vendor Product (1:7)
Position Logical drive number
ServerView RAID Manager display name
(Enclosure number: Port number)
one SAS controller two SAS controllers
9
10
11 12 13 14 15 16
17
18
19 20 21 22 23 24
쎻 쎻 쎻쎻
