390 Upgrade and Maintenance Manual RX2540 M2
10.6 Applying thermal paste
I – For the Japanese market, the service engineer must follow the
instruction provided separately.
– If the CPU upgrade or replacement kit contains a new CPU heat sink,
a thin layer of thermal compound has already been pre-applied to its
lower surface. In this case, please proceed with section "Installing
CPU heat sinks" on page 383.
Figure 273: Thermal paste syringe TC-5026
One thermal compound syringe (A3C40142460 / 34035576) contains thermal
paste for three CPUs.
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tool: tool-less
