RX2540 M2 Upgrade and Maintenance Manual 307
Expansion cards and backup units
8.6.4 Removing a GPGPU card in riser module 2
8.6.4.1 Preliminary steps
Ê If applicable, "Locating the defective server" on page 61
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê If applicable, remove all external cables from the expansion card to be
removed.
I If there is a cable installed to an expansion card in the upper slot, see
section "Note for installation with expansion cards in slot 5 and slot
11" on page 83.
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê If applicable, disconnect internal cables from the GPGPU card.
8.6.4.2 Removing the FBU
Ê If applicable, remove the FBU as described in section "Removing the FBU"
on page 297.
8.6.4.3 Removing the riser module 2
Ê Remove the riser module 2as described in section "Removing the riser
module 1 (FL)" on page 92.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver / nut driver 5 mm
