RX2540 M2 Upgrade and Maintenance Manual 185
Hard disk drives (HDD) and solid state drives (SSD)
7.3.5 Replacing the connector card
7.3.5.1 Preliminary steps
Ê "Locating the defective server" on page 61
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
7.3.5.2 Removing the SAS expander board
Ê Remove the assembled SAS expander holder as described in section
"Removing the SAS expander board" on page 174.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
