RX2540 M2 Upgrade and Maintenance Manual 561
15.2 Cabling plans
C27 CBL_PWR_6P_4
P_200 GTL
T26139-Y3939-V206 PCIe SSD rear to system
board
C28 CBL_4XPCIE_D
AL_200 AST
T26139-Y4040-V40 PCIe controller to PCIe
SSD rear (bundle) (short)
C29 CBL_SAS3.0_22
0 AST
T26139-Y4040-V39 SAS controller to SAS HDD
rear
C30 CBL_SAS_DEV_
PR_DAL
T26139-Y4044-V1 SAS controller to LTO
C31 CBL PWR 3CO
600
T26139-Y3986-V306 LTO to SAS BP
C32 CBL FBU03 550 T26139-Y4031-V102 SAS controller to FBU2
C33 CBL_SMB_4XBP T26139-Y4015-V605 4x 2.5-inch SAS BP to
system board (OOB)
C34 CBL PWR RDX
400
T26139-Y2193-V501 RDX power adapter cable
C35 CBL USB3.0AN
0,8M
T26139-Y4039-A80 RDX to system board
C36 CBL_4XPCIE_65
0
T26139-Y4040-V45 PCIe controller to PCIe
SSD front (bundle) (long)
C37 CBL_PWR_6P_4
P_500
T26139-Y3939-V210 PCIe SSD front to system
board
C38 CBL_PWR_GPU
_3_RAIL
T26139-Y3946-V704 E.g. M60/P100 GPU
No Name Cable number Routing
Table 5: List of used cables
