RX2540 M2 Upgrade and Maintenance Manual 583
No. Print Description
1 Front USB Front USB3.0
2 PWR 12V 3 +12 V power rail#3 / multiple usage
3 USB IN 1
4 USB3.0 int
5 Front VGA Front panel VGA connector
6 PWR 12V 1 +12 V power rail#1 / HDD backplane 1
7 PWR 12V 2 +12 V power rail#2 / HDD backplane 2
8LCD
9 Frontpanel 1 Front panel connector
10 Frontpanel 2 Front panel connector (flat cable)
11 FAN1 - FAN5 FAN connectors
12 OOB
13 SATA 7-10
14 SATA 5
15 SATA 1-4
16 SATA 6 DOM Connector for SATA DOM module
17 UFM Connector for USB Flash Module (UFM)
18 TPM Connector for Trusted Platform Module (TPM)
19 PWR 12V 4 +12 V power rail#4
20 PWR Power connector for PSU 1 + 2
21 microSD microSD card
22 COM1 Serial interface
