H3C S5120-SI Series

1-3
Field Description
The maximal retransmitting times
Maximum number of attempts for the device to
send authentication requests to the client
The maximum 802.1X user resource number per
slot
Maximum number of clients supported per board
Total current used 802.1X resource number Total number of online users
GigabitEthernet1/0/1 is link-up Status of port GigabitEthernet1/0/1
802.1X protocol is disabled Indicates whether 802.1X is enabled on the port
Handshake is disabled
Indicates whether handshake is enabled on the
port
Periodic reauthentication is disabled
Indicates whether periodic re-authentication is
enabled on the port
The port is an authenticator Role of the port
Authenticate Mode is Auto Authorization mode for the port
802.1X Multicast-trigger is enabled
Indicates whether the 802.1X multicast-trigger
function is enabled
Mandatory authentication domain
Mandatory authentication domain for users
accessing the port
Port Control Type is Mac-based Access control method for the port
Guest VLAN
Guest VLAN configured for the port. NOT
configured will be displayed if no guest VLAN is
configured.
Auth-fail VLAN
Auth-Fail VLAN configured for the port. NOT
configured means no Auth-Fail VLAN is
configured.
Max number of on-line users Maximum number of users supported on the port
EAPOL Packet
Counts of EAPOL packets sent (Tx) and
received (Rx)
Sent EAP Request/Identity Packets Number of EAP Request/Identity packets sent
EAP Request/Challenge Packets Number of EAP Request/Challenge packets sent
EAP Success Packets Number of EAP Success packets sent
Received EAPOL Start Packets Number of EAPOL Start packets received
EAPOL LogOff Packets Number of EAPOL LogOff packets received
EAP Response/Identity Packets
Number of EAP Response/Identity packets
received
EAP Response/Challenge Packets
Number of EAP Response/Challenge packets
received
Error Packets Number of erroneous packets received
Authenticated user User that has passed the authentication
Controlled User(s) amount Number of controlled users on the port
