Counter Shaft
Front
Bearing
Install the counter s
haft
front bearing
by
using the
installer
(49 0180 32
1A
).
13
.
Main Drive
Shaft
Bearing End
Play
Che
ck
the main drive shaft bearing end play
(A-B).
E
nd
play
Less
than
0.1
mm
(0.004
in)
Adjusting shims
I
0.15
mm
(0.006
in)
0.3
mm
(0.012
in
)
7A
-E
.
TRANSMISSION INSTALLATION
Install the transmission in the reverse order
of
removal.
Note:
a) Apply a very thin
coat
of grease
onto
the
splines
of
the
main drive shaft.
b)
Use
the turning
holder
(49
0259
440)
to
align
the
splines
on the main drive
shaft
with the
splines
in
the
clutch disc.
c)
Fill
the
transmission with a correct grade and
quantity
lubricant.
SPECIAL TOOLS
Puller set, bearing
Turning holder, main shaft
Wrench, main shaft lock
nu
t
Pusher, main drive shaft
Puller, bearing
Guide, sh
jft
fork rod
Guide, interlock pin
Installer,
main drive gear bearing
Installer, transmission bearing
