. Adjust the height
of
outer panel.
A-A
Cross Section
Adjust the difference
in
height between the outer
panel and the
roof
panel to less than 1.5 mm
(0.06
in).
Procedure to adjust B- B
Cross Section
1) Loosen mounting screws 1 and 2.
F
or
adjusting about 2
mm
(0.08
in),
it
may be
better
not
to
move screw
l.
2) Adjust by turning the adjust screw,
Turn clockwise
~
Up
Turn counterclockwise
~
Down
3)
Tighten mounting screws
I and
2.
Procedure to adjust
C-C
Cross
Section
1) Loosen the mounting screws and the adjusting screw.
For
easy adjustment,
do
not
overly loosen mounting
screws excessively.
2) Adjust by moving the outer panel from inside
or
outside.
3) Tighten the adjusting screw and the mounting screws
in
that
order.
11. Open the outer panel fully and install
the wind
deflector.
12. Insert the inner trim into t
he
space between the
frame and lower panel, insuring that the trim
enters deeply inside.
Note:
Do not damage the inner trim film surface with
an
edge of
the
rail
cover
or
guide
rail.
13.
Open
the outer panel about
100
mm
(3.94
in)
and install the inner
lrim.
