lOA
Fig.
10A
- 3
Fig.
10A
- 4
Fig. 10A- 5
•
Fig.
10A
- 6
lOA:
3
10A
-
A-5
. Fluid Level
Check
Check
the fluid level in the power steering rese
rv
oir.
The level must show between the
"FUL
L" and
"
LOW
"
level marks on the reservoir. Add
fl
uid meeting
spec·
ifications
if
necessary. Do
not
overfill.
10A
-A-O.
Fluid Leak
Check
1.
With the engine idling,
tum
the steering wheel left
to
right several times. Check
all possible leak
age
points.
2.
Torque
all
loose fittings
to
specification. Replace
damaged lines and seats.
10A-A
- 7.
Pump Belt Check
I.
If
the belt
is
broken, glazed, or worn, replace the
belt with a new one.
2.
If
the belt
is
noisy, check the tension
of
the belt.
Also, check for misaligned pulleys.
3.
When the belt
is
pressed down with
10
kg
(22
lb)
force, the belt should deflect the specified amou
nt.
For new belt
8 -
IO
mm
0.31 - 0.39
in
For used belt
11-13
mm
0.43-0.5
1
in
10A
-B
.
STEERING
GEAR REMOVAL
Remove the power steering gear in
the
numerical order.
1. Disconnect the negative battery cable from the
battery.
2.
Column cover and switch panel.
3. Fixing bracket bolts.
4.
Remove the set plate attaching nuts and slides the
set plate toward the steering wheel.
5.
Loosen the bolt securing the flexible coupling
to th
e
wonn
shaft.
To Next Page
