Mazda 626 1981 - 7 B-00

7B
AUTOMATIC
TRANSMISSION
7B-A. TRANSMISSION REMOVAL ........... ... .. 7B : 1
7B-8. TRANSMISSION DISASSEMBLY ............. 78: 1
7B-C. OVERHAUL OF
MAIN COMPONENTS ........ 7B : 4
78 - C- I. Front Clutch . . . . . . . . . . . . . . . . . . . . 78 : 4
7B-C-2. Rear Clutch ..... ..... .......... 78 : 5
78-C-3. Low and Reverse Brake ............ 78 : 6
78-C-4. Servo ......................... 7B : 8
78 - C-5. Governor and Oil Distributor ........ 78 : 9
7B-C-6. Oil Pump .... .... .............. 78 : 9
78-C-7. Control Valve Body ............... 7B: 11
78-C-8. Connecting Shell and Sun Gear ...... 78 : 12
78 - C- 9. Internal Drive Flange ........ ...... 78 : 13
78-C-10. Planet Carrier ................... 78 : 13
78-C-11. One-wa y Clutch ...... ............ 78 : 13
78 -C - 12. Air Pressure Checks .............. . 78: 14
78-D. TRANSMISSION ASSEMBLY ......... ....... 7B: 14
78-E. TRANSMISSION INSTALLATION ............ 78: 16
7B-F. HYDRAULIC CONTROL INSPECTION ......... 7B: 16
7B-F-1. Checking Transmission Fluid Level .... 78 : 16
78-F-2. Checking Engine Idle Speed ......... 7B : 16
78-F-3. Checking Line Pressure ............ 78: 17
7B-F-4. Checking Governor Pressure . .. ...... 78: 17
78-F-5. Stall Test . . . . . . . . . . . . . . . . . . . . . . 78 : 17
78-F-6. Checking Shift Point . ............. 7B : 18
78-G. SHIFT CONTROL LINKAGE ................ 78: 18
78 - G-I. Adjusting ManuaJ Linkage ... ....... 78 : 18
78-G-2. Adjusting Selector Lever Knob ....... 7B : 18
78-G-3. Adjusting Engine Idle Speed ......... 78 : 19
78-G-4. Adjusting Kick-down Switch . . ....... 7B : 19
7B-G-5. Adjusting Inhibitor Switch .......... 78 : J 9
78-G-6. Kick-down Switch ................ 78 : 20
78-G-7. Inhibitor Switch ................. 78: 20
•
78-G-8. Selector Lever ... .. .............. 7B : 20
SPECIAL
TOOLS ..... . .......... ..... ... ..... 78 : 21
..
