14-A.
BONNET
14-A-1
.
Replacing
Bonnet
Remove the bonnet in the numericaJ order.
Open
the bonnet.
Mark the bonnet hinge locations on the bonnet for
proper reinstallation.
I. Bonnet support attaching bolts
2. Bonnet attaching bolts
3.
Bonnet
Install the bonnet in the reverse order
of
removal.
Adjust the bonnet
if
necessary. (Refer
to
Par
14-A-2)
14-A-2
. Adjusting Bonnet
I.
Adjust t
he
bonnet fore-and-
aft
and side-to-side
by
loosening the bonnet attaching bolts.
2. Adjust the bonnet
up
-and-<lown
by
loosening the
hinge attaching bolts.
3.
Ad
just the bonnet lock mechanism after the
bo
nn
et
has been aligned. The bonnet lock female
part
can be
moved fore-and-aft and side-to-side
to
align
it
with
the bonnet lock male
part
by loosening the attaching
bolts.
14- B.
TRUNK
LIO
14
-
B-1.
Replacing
Trunk
Lid
Remove the trunk lid in the numerical order.
Open
the trunk lid.
Mark the
trunk
lid
hinge locations on the trunk lid
for proper reinstallation.
l . Trunk lid hinge attaching
nut
s
2. Trunk lid
Install the trunk lid
in
the reverse order
of
removal
Adjust the trunk lid
if
necessary (See Par. 14- B
-2)
