14
fig.
14-49
fig
.
14-50
Fig.
14-61
fig.
14-52
14:
13
(Hardtop)
1.
Refer
to
the
Par.
14-J-
l
and remove the door trim.
2. Remove the screws attaching the both ends
of
the
weatherstrip
to
the door.
3.
Pull
the weatherstrip from the retaining clips, and
remove the weatherstrip without damaging the
rubber
if
the weatherstrip
is
to
be used again.
4.
Remove the weatherstrip retaining clips from the
door.
5.
Inspect the weatherstrip for crack, deformation
and damage.
If
defective, replace it.
6. Fit the retaining clips
to
the weatherstrip w
ith
a
plier.
7.
Position
the weatherstrip to the door and fit the
retaining clips
into
place.
To install, reverse the removal procedure.
14
-J.
FRONT DOOR
14
-
J-1
.
Front
Door Window Regulator
and
Glass
a.
Replacement
Remove the door window regulator and glass in the
numerical order.
With
the window glass raised
to
full
down position.
I.
Window regulator handle
2. Inner handle attaching screw
3. Ann rest
4.
Door trim
5.
D
oo
r screen
6. Glass stopper (Hardtop only)
7. Weatherstrip (inner and outer)
8. Door glass attaching bolts and nuts
9. Remove the window glass assembly from the regu-
lator and take
it
upward.
10. Take
out
the regulator from the service hole.
To install, reverse the removal procedure.
Note:
Adjust
the
regulator
and
check
the
operation
of
the
regulator.
..
·
