Ott
set
1·
mm
(0.04
in)
Taper
slee
ve
Fig.
1-86
.
tpilii;j1$1'4
""'
Fig.
1-87
Fig.
1-88
1
2.
Tighten the cylinder head bolts temporarily.
3. Move the rocker arm
suppo
rt
ers and offset each
of
the
rocker arms 1 mm
(0.
04
in) from the valve
stem center.
4.
Tighten
the
cylinder
head
bolls
evenly
to
8.2
-
8.8
m·kg (59
-
64
ft·lb) in the sequence.
5.
Tighten the
bolt
attaching the cylinder head
to
the
cylinder block.
6.
Lock the flywheel with the brake
(49
0118
271A)
and tighten
the
camshaft sprocket lock
nut
to
7.0
- 8.0 m-kg
(51 -
58
ft·lb)
with the spanner
(49
0164
631
A). Bend the tab
of
the
lock washer.
7. Aligning
the
key groove
with
the
pin,
install
the
distributor drjve gear
to
the camsh
aft.
Tighten
the lock
nut
to
7.0
-
8.0
m·
kg
(51
-
58
ft·lb)
and
bend
the lab
of
the lock washer.
I :
