Fig.
4-39
F
ig.4-
40
Fig.
4-41
4
7.
Turn the mixture adjust screw to set the idle rpm
at the highest.
8.
Re-adjust the idle speed to following specifications
by using throttle adjust screw.
Idle speed
670
rpm in
neutral
(With
manu
al transmission)
850
rpm
in
"N"
range
(With
automatic
transmission)
9.
Tum
the mixture adjust screw clockwise until the
following specifications.
650
rpm in
neut
ral (with manual transmission)
820
rpm in
" N" range (with a
ut
o
matic
transmission)
I 0.
Check
co
concentration.
If
it
is
less than
1
%,
turn
the mixture adjust screw counter-clockwise
l/4
tum.
11. Reconnect the
air
hoses and check the idle speed
to
be
at following specifications.
If
not,
set the
idle speed lo 650 rpm by using throttle adjust
screw.
650
rpm in
neutral
650
rpm
"D"
range
(with manual transm
is
sion)
(with
automatic
transmission)
12.
Fit a blind plug
to
the mixture adjust screw.
Note
:
All
accessories
should
be
OFF
.
4-
B.
CARBURETOR LINKAGE
4-B-1.
Checking Carburetor Linkage
Check
the throttle linkage, accelerator linkage and
choke linkage for proper operation.
Examine the choke control for free operation.
4:
