Product checking and accessories
12
INTRODUCTION
1.1 Product checking and accessories
Unpack the product and check the rating plate and the capacity plate of the inverter to ensure that the model agrees with the
order and the product is intact.
Inverter model
 Specification differs by the type. Major differences are shown in the table below.
NOTE
• Hereinafter, the inverter model name consists of the rated current and the applicable motor capacity.
(Example) FR-A820-00046(0.4K)
Type Monitor output
Initial setting
Built-in
EMC
filter
Control
logic
Rated
frequency
Pr.19 Base
frequency voltage
FM
(terminal FM
equipped model)
Terminal FM (pulse train output)
Terminal AM (analog voltage output (0 to ±10 VDC))
OFF Sink logic 60 Hz
9999 (same as the
power supply voltage)
CA
(terminal CA
equipped model)
Terminal CA (analog current output (0 to 20 mADC))
Terminal AM (analog voltage output (0 to ±10 VDC))
ON Source logic 50 Hz
8888 (95% of the
power supply voltage)
Rating plate
Input rating
Output rating
SERIAL
Manufactured
year and month
Inverter model
F R - A 8 2 0 - 0.4K - 1
400V class
Symbol Voltage class
200V class
4
2
CA
Symbol Type ∗1
FM
-2
-1
Symbol Description
0.4K to 500K
00023 to 12120
ND rated inverter capacity (kW)
SLD rated inverter current (A)
IP55 compatible model
Symbol Structure, functionality
Standard model
6
0
Separated converter type 2
Symbol
Circuit board coating
(conforming to IEC60721-3-3 3C2/3S2)
Not usedNot used
With
With
Plated conductor
Not used
With
Not used
-06
-60
