5.13.3 Offline auto tuning for a PM motor (motor
constants tuning)
The offline auto tuning for an PM motor enables the optimal operation of a PM motor.
• What is offline auto tuning?
Under PM sensorless vector control, setting motor constants automatically (offline auto tuning) enables optimal
operation of motors even when motor constants vary or when the wiring distance is long. IPM and SPM motors other
than IPM motor MM-CF can also be used.
For the offline auto tuning under Advanced magnetic flux vector control, Real sensorless vector control, and vector
control, refer to page 442.
Pr. Name
Initial
value
Setting range Description
684
C000
Tuning data unit switchover
0
0 Internal data converted value
1
The value is indicated with "A, , mH or
mV".
1002
C150
Lq tuning target current
adjustment coefficient
9999
50 to 150%
Perform adjustment if the overcurrent
protective function is activated during
tuning.
9999 No adjustment
71
C100
Applied motor
0
0 to 6, 13 to 16, 20, 23, 24, 30,
33, 34, 40, 43, 44, 50, 53, 54, 70,
73, 74, 330, 333, 334, 8090,
8093, 8094, 9090, 9093, 9094
By selecting a motor, the thermal
characteristic and motor constant of each
motor are set.
80
C101
Motor capacity
9999
0.4 to 55 kW

Applied motor capacity setting.
0 to 3600 kW

9999 V/F control
81
C102
Number of motor poles
9999
2, 4, 6, 8, 10, 12 Set the number of motor poles.
9999 V/F control
9
C103
Electronic thermal O/L relay
Rated
inverter
current

0 to 500 A
Set the rated motor current.
0 to 3600 A

83
C104
Rated motor voltage
200/400
V

0 to 1000 V Set the rated motor voltage (V).
84
C105
Rated motor frequency
9999
10 to 400 Hz Set the rated motor frequency (Hz).
9999
The MM-CF constant is used when the
IPM motor MM-CF is selected, and the
inverter internal data is used when a PM
motor other than MM-CF is selected. Use
the correct setting according to the motor
specification.
702
C106
Maximum motor frequency
9999
0 to 400 Hz Set the maximum frequency of the motor.
9999
The MM-CF motor maximum frequency is
used when the IPM motor MM-CF is
selected, and Pr.84 setting is used when
a PM motor other than MM-CF is
selected.
707
C107
Motor inertia (integer)
9999 10 to 999, 9999
Set the motor inertia.
9999: Uses MM-CF inertia for IPM motor
MM-CF.
724
C108
Motor inertia (exponent)
9999 0 to 7, 9999
96
C110
Auto tuning setting/status
0
0, 101 No offline auto tuning.
1
Performs offline auto tuning without
rotating the motor. (motor other than IPM
motor MM-CF)
11
Performs offline auto tuning without
rotating the motor (V/F control, IPM motor
MM-CF).
