Mitsubishi FR-A800

Motor rating
SPECIFICATIONS
693
8
*1 80% output in the high-speed range. (The output is reduced when the speed is 2400 r/min or more. Contact us separately for details.)
*2 A dedicated motor of 3.7 kW or less can be run at the maximum speed of 3600 r/min. Consult our sales office when using the motor at the maximum speed.
*3 Power (current) at 50 Hz/60 Hz.
*4 Since a motor with brake has a window for gap check, the protective structure of both the cooling fan section and brake section is IP20. S of IP23S is an
additional code indicating the condition that protection from water intrusion is established only when a cooling fan is not operating.
*5 The value when high carrier frequency is set (Pr.72 = 6, Pr.240 = 0).
*6 The 12 V power supply is required as the power supply for the encoder.
*7 The cooling fan is equipped with a thermal protector. The cooling fan stops when the coil temperature exceeds the specified value in order to protect the fan
motor. A restrained cooling fan or degraded fan motor insulation could be causes for the rise in coil temperature.The cooling fan re-starts when the coil
temperature drops to normal.
*8 The cooling fan voltage and input values are the basic specifications of the cooling fan alone and free air values. The input value becomes slightly larger
when it is rotated by this motor due to an increased workload, but the cooling fan can be used as it is.When preparing a thermal relay at the user side, use
the recommended thermal setting.
Vector control dedicated motor SF-THY
*1 The 12 V power supply or the control terminal option (FR-A7PS) is required as the power supply for the encoder.
*2 A motor with a thermal protector is also available. Contact your sales representative.
Motor type SF-THY
Applicable inverter
(ND rating)
FR-A820-[ ]K FR-A840-[ ]K
90 90 110 132 160 185 220 280
Rated output (kW) 75 75 90 110 132 160 200 250
Rated torque (N·m)
477 477 572 700 840 1018 1273 1591
Maximum torque 150%60 s
(N
·m)
715 715 858 1050 1260 1527 1909 2386
Rated speed (r/min) 1500 1500
Maximum speed (r/min) 2400 2400 1800
Frame No. 250MD 250MD 250MD 280MD 280MD 280MD 280L 315H
Inertia moment J (kg·m
2
)
1.1 1.1 1.7 2.3 2.3 4.0 3.8 5.0
Noise 90 dB 90 dB 95 dB
Cooling fan
Voltage Three-phase, 200 V/50 Hz, 200 V/60 Hz, 220 V/60 Hz (400 V class cooling fan is available upon order)
Input (W)
50 Hz
750
400 400 400 400 400 750 750
60 Hz 750 750 750 750 750 1500 1500
Approx. mass (kg) 610 610 660 870 890 920 1170 1630
Common specifications
Surrounding air
temperature, humidity
-10 to +40°C (non-freezing), 90%RH or less (non-condensing)
Structure Totally enclosed forced draft system
Detector Encoder 2048P/R, A phase, B phase, Z phase +12 VDC power supply *1
Equipment Encoder, thermal protector*2, fan
Insulation Class F
Vibration rank V10
Dedicated encoder
Resolution 2048 pulse/rev
Power supply voltage 12 VDC±10%
Current consumption 90 mA
Output signal form A, B phases (90° phase shift) Z phase: 1 pulse/rev
Output circuit Complementary (constant voltage output matched by emitter follow)
Output voltage
"H" level: Power supply voltage 9 V or more (I
OH: -20 mA)
"L" level: Power supply voltage 3 V or less (I
OL: 20 mA)
