(C) Motor constant parameters
PARAMETERS
441
5
GROUP
C
SF-PR heavy duty setting
• When the SF-PR motor is selected (Pr.71="70, 73, 74"), the SF-PR heavy duty setting can be selected by setting Pr.81
Number of motor poles according to the number of the SF-PR motor poles.
• When the SF-PR heavy duty setting is selected, the Pr.0 Torque boost setting is automatically changed to enable output of
the 6 Hz 150% torque under V/F control.
NOTE
• When using the SF-PR heavy duty setting, set Pr.14 Load pattern selection = "0" (initial value).
• When the Pr.0 setting is changed from its initial value, the automatic change is not performed.
Automatic change of Pr.0 Torque boost and Pr.12 DC injection brake
operation voltage
• When initial values are set in Pr.0 and Pr.12, the Pr.0 and Pr.12 settings are automatically changed to the values in the
table below by changing the Pr.71 setting.
 When changed to Pr.71 = "0, 2 to 6, 20, 23, 24, 40, 43, or 44" (standard motor)
 When changed to Pr.71 = "1, 13 to 16, 50, 53, or 54" (constant-torque motor)
 When changed to Pr.71 = "70, 73, or 74" (SF-PR)
NOTE
• When the Pr.0 and Pr.12 settings are changed from their initial values, the automatic change is not performed.
???????
Parameters referred to
Pr.0 Torque boost page 597
Pr.12 DC injection brake operation voltage page 605
Pr.14 Load pattern selection page 600
Pr.96 Auto tuning setting/status page 442
Pr.100 to Pr.109 (Adjustable 5 points V/F) page 603
Pr.178 to Pr.189 (input terminal function selection) page 430
Pr.684 Tuning data unit switchover page 442
Pr.800 Control method selection page 164
Inverter Pr.0 value (%) after automatic change
Pr.12 value (%) after
automatic change
FR-A820-[] FR-A840-[]
Standard
motor

Constant-
torque
motor

SF-PR 
Standard
motor

Constant
-torque
motor

SF-PR

Heavy duty setting
Light duty
setting
SLD
/LD
ND/
HD
SLD
/LD
ND/
HD
Pr.81
=2
Pr.81
=4
Pr.81
=6
Pr.81
2,4,6
00046(0.4K) 00023(0.4K) 6 6 4444 4 4 4
00077(0.75K) 00038(0.75K) 6 6 7.4 6 6.4 4 4 4 4
00105(1.5K) 00052(1.5K) 4 4 5.8 5 3.7 3 4 4 2.5
00167(2.2K) 00083(2.2K) 4 4 6 4.5 3.3 2.5 4 4 2.5
00250(3.7K) 00126(3.7K) 4 4 6.4 4.5 4.2 2.5 4 4 2.5
00340(5.5K) 00170(5.5K) 3 2 4.5 3.7 3.3 2 4 2 2
00490(7.5K) 00250(7.5K) 3 2 4.4 4.5 3.8 2 4 2 2
00630(11K) 00310(11K) 2 2 3.5 3.3 3.5 1.5 2 2 1.5
00770(15K) 00380(15K) 2 2 4.5 3 3.5 1.5 2 2 1.5
00930(18.5K) 00470(18.5K) 2 2 4 3.2 3 1.5 2 2 1.5
01250(22K) 00620(22K) 2 2 2.5 3.4 3 1.5 2 2 1
01540(30K) 00770(30K) 2 2 3 2 2.5 1 2 2 1
01870(37K) 00930(37K) 2 2 2 2.5 2.6 1 2 2 1
02330(45K) 01160(45K) 1.5 2 1.5 2 2 2 2.4 1 2 2 1
03160(55K) 01800(55K) 1.5 2 1.5 2 2 2 0.7 0.7 2 2 1
03800(75K)
or higher
02160(75K)
or higher
1 1 1111 1 1 1
Caution
 Make sure to set this parameter correctly according to the motor used. Incorrect setting may cause
the motor and inverter to overheat and burn.
