Mitsubishi FR-A800

Connection of motor with encoder (vector control)
70
INSTALLATION AND WIRING
• Combination with the SF-V5RU1, 3, 4, and SF-THY (ND rating)
Models surrounded by black borders and 400 V class are developed upon receipt of order.
 The maximum speed is 2400 r/min.
 80% output in the high-speed range. (The output is reduced when the speed is 2400 r/min or faster.)
 90% output in the high-speed range. (The output is reduced when the speed is 1000 r/min or faster.)
 For motors with overload capacity 150% 60 s ("Y" at the end of their model names), contact your sales representative.
SF-V5RU[ ]1 (1:2) SF-V5RU[ ]3 (1:3) SF-V5RU[ ]4 (1:4)
Voltage 200 V class
Rated
speed
1000 r/min 1000 r/min 500 r/min
Base
frequency
33.33 Hz 33.33 Hz 16.6 Hz
Maximum
speed
2000 r/min 3000 r/min 2000 r/min
Motor
capacity
Motor
frame
number
Motor model
Inverter
model
FR-A820-[]
Motor
frame
number
Motor model
Inverter
model
FR-A820-[]
Motor
frame
number
Motor model
Inverter
model
FR-A820-[]
1.5 kW 100L SF-V5RU1K1 (Y) 00167(2.2K) 112M SF-V5RU1K3 (Y) 00167(2.2K) 132M SF-V5RU1K4 (Y) 00167(2.2K)
2.2 kW 112M
SF-V5RU2K1 (Y) 00250(3.7K) 132S SF-V5RU2K3 (Y) 00250(3.7K) 160M SF-V5RU2K4 (Y) 00250(3.7K)
3.7 kW 132S
SF-V5RU3K1 (Y) 00340(5.5K) 132M SF-V5RU3K3 (Y) 00340(5.5K) 160L SF-V5RU3K4 00340(5.5K)
5.5 kW 132M SF-V5RU5K1 (Y) 00490(7.5K) 160M SF-V5RU5K3 (Y) 00490(7.5K) 180L SF-V5RU5K4 (Y) 00490(7.5K)
7.5 kW 160M
SF-V5RU7K1 (Y) 00630(11K) 160L SF-V5RU7K3 (Y) 00630(11K) 200L SF-V5RU7K4 (Y) 00630(11K)
11 kW 160L
SF-V5RU11K1 (Y) 00770(15K) 180M SF-V5RU11K3 (Y) 00770(15K) 225S SF-V5RU11K4 (Y) 00770(15K)
15 kW 180M
SF-V5RU15K1 (Y) 00930(18.5K) 180L SF-V5RU15K3 (Y) 00930(18.5K) 225S SF-V5RU15K4 00930(18.5K) 
18.5 kW 180L SF-V5RU18K1 (Y) 01250(22K) 200L SF-V5RU18K3 (Y) 01250(22K) 250MD SF-THY 01250(22K)
22 kW 200L
SF-V5RU22K1 (Y) 01540(30K) 200L SF-V5RU22K3 (Y) 01540(30K) 280MD SF-THY 01540(30K)
30 kW 200L
 SF-V5RU30K1 (Y) 01870(37K) 225S SF-V5RU30K3 (Y) 01870(37K) 280MD SF-THY 01870(37K)
37 kW 225S
SF-V5RU37K1 (Y) 02330(45K) 250MD SF-THY 02330(45K) 280MD SF-THY 02330(45K)
45 kW 250MD SF-THY 03160(55K) 250MD
 SF-THY 03160(55K) 280MD SF-THY 03160(55K)
55 kW 250MD SF-THY 03800(75K) 280MD
 SF-THY 03800(75K) 280L SF-THY 03800(75K)
