5.12.6 Bias and gain for torque (magnetic flux) and set
voltage (current)
Changing the function of analog input terminal
• The initial value for terminal 1 used as analog input is set to speed setting auxiliary (speed limit auxiliary), and terminal 4 is
set to speed command (speed limit). To use the analog input terminal as torque command, torque limit, or magnetic flux
command, set Pr.868 Terminal 1 function assignment, Pr.858 Terminal 4 function assignment to change the function.
(Refer to page 410.)
The magnetic flux command is valid under vector control only.
The magnitude (slope) of the torque can be set as desired in relation to the torque setting signal (0 to 5 VDC, 0 to 10
VDC, or 4 to 20 mA).
Use Pr.73 Analog input selection or Pr.267 Terminal 4 input selection to switch among input 0 to 5 VDC, 0 to 10 V,
and 4 to 20 mA. (Refer to page 406.)
Pr. Name
Initial
value
Setting
range
Description
C16
(919) 
T110
Terminal 1 bias command (torque)
0% 0 to 400%
Set the torque (magnetic flux) of the bias side of
terminal 1 input.
C17
(919)

T111
Terminal 1 bias (torque)
0% 0 to 300%
Set the converted % on bias side voltage of terminal 1
input.
C18
(920)

T112
Terminal 1 gain command (torque)
150% 0 to 400%
Set the torque (magnetic flux) of the gain (maximum) of
terminal 1 input.
C19
(920) 
T113
Terminal 1 gain (torque)
100% 0 to 300%
Set the converted % on the gain side voltage of terminal
1 input.
C38
(932)

T410
Terminal 4 bias command (torque)
0% 0 to 400%
Set the torque (magnetic flux) of the bias side of
terminal 4 input.
C39
(932)

T411
Terminal 4 bias (torque)
20% 0 to 300%
Set the converted % on the bias side current (voltage)
of terminal 4 input.
C40
(933) 
T412
Terminal 4 gain command (torque)
150% 0 to 400%
Set the torque (magnetic flux) of the gain (maximum) of
terminal 4 input.
C41
(933)

T413
Terminal 4 gain (torque)
100% 0 to 300%
Set the converted % on gain side current (voltage) of
terminal 4 input.
241
M043
Analog input display unit
switchover
0
0% display
Select the unit for analog input display.
1V/mA display
 The parameter number in parentheses is the one for use with the LCD operation panel and the parameter unit.
