(M) Monitor display and monitor output signal
368
PARAMETERS
NOTE
• The number of display digits on the cumulative energization time (Pr.52 = "20"), actual operation time (Pr.52 = "23"),
cumulative power (Pr.52 = "25") and cumulative energy saving (Pr.52 = "51") does not change.
Minus sign display for the monitors (Pr.290)
• Values with minus signs can be output from the terminal AM (analog voltage output) and can be displayed on the
operation panel. For a list of the monitors that can output values with minus signs, refer to the monitor description list (on
page 360).
NOTE
• When terminal AM (analog voltage output) is "output with a minus sign", the output will be within the -10V DC to +10V DC
range. Connect the meter with which output level is matched.
• Parameter unit (FR-PU07) displays only positive values.
Monitor filter (Pr.1106 to Pr.1108)
• The response level (filter time constant) of the following monitor indicators can be adjusted.
Pr.30 Regenerative function selection, Pr.70 special regenerative brake duty page 614
Pr.37 motor speed display, Pr.144 Speed setting switchover page 357
Pr.55 Frequency monitoring reference, Pr.56 Current monitoring reference, Pr.866 Torque monitoring reference page 369
Pr.290 setting Terminal AM output Operation panel display
Monitoring via
communication
0 (initial value)
1 Output with a minus sign
2 Displayed with minus sign.
3 Output with a minus sign Displayed with minus sign.
4 Displayed with minus sign.
5 Output with a minus sign Displayed with minus sign.
6 Displayed with minus sign. Displayed with minus sign.
7 Output with a minus sign Displayed with minus sign. Displayed with minus sign.
: Output without minus sign
(positive values only)
Pr. Monitor number Monitor indicator name
1106
7 Motor torque
17 Load meter
32 Torque command
33 Torque current command
1107 6 Running speed
1108 18 Motor excitation current
