Outline dimension drawings

SPECIFICATIONS

697

8.4 Outline dimension drawings

8.4.1 Inverter outline dimension drawings

FR-A820-00046(0.4K), FR-A820-00077(0.75K)

FR-A820-00105(1.5K), 00167(2.2K), 00250(3.7K)

FR-A840-00023(0.4K), 00038(0.75K), 00052(1.5K), 00083(2.2K), 00126(3.7K)

(Unit: mm)

110

7.5 245 (7.5)

260(1.5)

7.5

2-φ6 hole

Inverter Model D D1

FR-A820-00046(0.4K) 110 20

FR-A820-00077(0.75K) 125 35

150

140

(1.5)

245 7.5

260

45.5

(7.5)

12.5 125

FAN

2-φ6 hole

 FR-A840-00023(0.4K) to

00052(1.5K) are not provided

with a cooling fan.


