Mitsubishi FR-A800

(T) Multi-Function Input Terminal Parameters
430
PARAMETERS
5.12.8 Input terminal function selection
 The initial value is for standard models and IP55 compatible models.
 The initial value is for separated converter types.
Input terminal function assignment
• Using Pr.178 to Pr.189, set the functions of the input terminals
• Refer to the following table and set the parameters.
Use the following parameters to select or change the input terminal functions.
Pr. Name
Initial
value
Initial signal Setting range
178
T700
STF terminal function
selection
60 STF (Forward rotation command)
0 to 20, 22 to 28, 37, 42 to 48,
50, 51, 60, 62, 64 to 74, 76,
77 to 80, 87, 92 to 96, 9999
179
T7001
STR terminal function
selection
61 STR (Reverse rotation command)
0 to 20, 22 to 28, 37, 42 to 48,
50, 51, 61, 62, 64 to 74, 76,
77 to 80, 87, 92 to 96, 9999
180
T702
RL terminal function
selection
0 RL (Low-speed operation command)
0 to 20, 22 to 28, 37, 42 to 48,
50, 51, 62, 64 to 74, 76,
77 to 80, 87, 92 to 96, 9999
181
T703
RM terminal function
selection
1 RM (Middle-speed operation command)
182
T704
RH terminal function
selection
2 RH (High-speed operation command)
183
T705
RT terminal function
selection
3 RT (Second function selection)
184
T706
AU terminal function
selection
4 AU (Terminal 4 input selection)
185
T707
JOG terminal function
selection
5 JOG (Jog operation selection)
186
T708
CS terminal function
selection
6 CS (Electronic bypass function)
187
T709
MRS terminal function
selection
24 MRS (Output stop)
10
 X10 (Inverter run enable signal)
188
T710
STOP terminal function
selection
25
STP (STOP) (Start self-holding
selection)
189
T711
RES terminal function
selection
62 RES (Inverter reset)
Pr. Name
Initial
value
Setting range Description
699
T740
Input terminal filter
9999
5 to 50 ms Set the time to delay the input terminal response.
9999 No input terminal filter
Setting
Signal
name
Function Related parameter
Refer to
page
0RL
Pr.59 = 0 (initial value) Low-speed operation command
Pr.4 to Pr.6, Pr.24 to Pr.27,
Pr.232 to Pr.239
328
Pr.59  0
 Remote setting (setting clear) Pr.59 295
Pr.270 = 1, 3, 11, 13
 Stop-on-contact selection 0 Pr.270, Pr.275, Pr.276 478
1RM
Pr.59 = 0 (initial value) Middle-speed operation command
Pr.4 to Pr.6, Pr.24 to Pr.27,
Pr.232 to Pr.239
328
Pr.59  0
 Remote setting (deceleration) Pr.59 295
2RH
Pr.59 = 0 (initial value) High-speed operation command
Pr.4 to Pr.6, Pr.24 to Pr.27,
Pr.232 to Pr.239
328
Pr.59  0
 Remote setting (acceleration) Pr.59 295
3RT
Second function selection
Pr.44 to Pr.51, Pr.450 to Pr.463,
Pr.569, Pr.832, Pr.836, etc.
434
Pr.270 = 1, 3, 11, 13
 Stop-on-contact selection 1 Pr.270, Pr.275, Pr.276 478
4 AU Terminal 4 input selection Pr.267 406
5 JOG Jog operation selection Pr.15, Pr.16 327
