Mitsubishi FR-A800

(T) Multi-Function Input Terminal Parameters
PARAMETERS
431
5
GROUP
T
6CS
Selection of automatic restart after instantaneous power
failure, flying start
Pr.57, Pr.58, Pr.162 to Pr.165,
Pr.299, Pr.611
528, 534
Electronic bypass function
Pr.57, Pr.58, Pr.135 to Pr.139,
Pr.159
464
7 OH External thermal relay input
 Pr.9 331
8REX
15-speed selection
(Combination with multi-speeds of RL, RM, and RH)
Pr.4 to Pr.6, Pr.24 to Pr.27,
Pr.232 to Pr.239
328
9 X9 Third function selection Pr.110 to Pr.116 434
10 X10
Inverter run enable signal (FR-HC2/FR-CV/FR-CC2
connection)
Pr.30, Pr.70, Pr.599 614
11 X11
FR-HC2/FR-CC2 connection, instantaneous power failure
detection
Pr.30, Pr.70 614
12 X12 PU operation external interlock Pr.79 306
13 X13 External DC injection brake operation start Pr.10 to Pr.12 605
14 X14 PID control valid terminal Pr.127 to Pr.134, Pr.575 to Pr.577 501
15 BRI Brake opening completion signal Pr.278 to Pr.285 473
16 X16
PU/External operation switchover
(External operation with X16-ON)
Pr.79, Pr.340 306
17 X17
Load pattern selection forward/reverse rotation boost (For
constant-torque with X17-ON)
Pr.14 600
18 X18 V/F switchover (V/F control with X18-ON) Pr.80, Pr.81, Pr.800 164
19 X19 Load torque high-speed frequency Pr.270 to Pr.274 481
20 X20 S-pattern acceleration/deceleration C switchover Pr.380 to Pr.383 290
22 X22
Orientation command (for FR-A8AP)

Pr.350 to Pr.369 488
23 LX Pre-excitation/servo ON
 Pr.850 605
24 MRS
Output stop Pr.17 433
Electronic bypass function
Pr.57, Pr.58, Pr.135 to Pr.139,
Pr.159
464
25
STP
(STOP)
Start self-holding selection Pr.250 436
26 MC Control mode switchover Pr.800 164
27 TL Torque limit selection Pr.815 185
28 X28 Start-time tuning start external input Pr.95 460
37 X37 Traverse function selection Pr.592 to Pr.597 484
42 X42 Torque bias selection 1 (for FR-A8AP)
 Pr.840 to Pr.845 202
43 X43 Torque bias selection 2 (for FR-A8AP)
 Pr.840 to Pr.845 202
44 X44 P/PI control switchover (P control with X44-ON) Pr.820, Pr.821, Pr.830, Pr.831 192
45 BRI2 Second brake sequence open completion Pr.641 to Pr.649 473
46 TRG Trace trigger input Pr.1020 to Pr.1047 547
47 TRC Trace sampling start/end Pr.1020 to Pr.1047 547
48 X48 Power failure stop external Pr.261 to Pr.266, Pr.294, Pr.668 540
50 SQ Sequence start Pr.414 545
51 X51 Fault clear Pr.414 545
60 STF
Forward rotation command (Assignable to the STF terminal
(Pr.178) only)
Pr.250 436
61 STR
Reverse rotation command (Assignable to the STR terminal
(Pr.179) only)
Pr.250 436
62 RES Inverter reset Pr.75 259
64 X64 PID forward/reverse action switchover Pr.127 to Pr.134 501
65 X65 PU/NET operation switchover (PU operation with X65-ON) Pr.79, Pr.340 306
66 X66
External/NET operation switchover (NET operation with
X66-ON)
Pr.79, Pr.340 306
67 X67
Command source switchover (Command by Pr.338, Pr.339
enabled with X67-ON)
Pr.338, Pr.339 316
68 NP Simple position pulse train sign Pr.291, Pr.419 to Pr.430, Pr.464 245
69 CLR Simple position droop pulse clear Pr.291, Pr.419 to Pr.430, Pr.464 245
70 X70 DC feeding operation permission
 Pr.30 614
71 X71 DC feeding cancel
 Pr.30 614
72 X72 PID integral value reset Pr.127 to Pr.134, Pr.575 to Pr.577 501
73 X73 Second PID P control switchover Pr.127 to Pr.134, Pr.575 to Pr.577 501
74 X74 Magnetic flux decay output shutoff signal Pr.850 608
Setting
Signal
name
Function Related parameter
Refer to
page
