Motor rating
692
SPECIFICATIONS
8.2 Motor rating
Vector control dedicated motor SF-V5RU (1500r/min series)
200V class
Motor type
SF-V5RU[ ]K
123571115182230 3745 55
Applicable inverter model
FR-A820-[ ]K (ND rating)
2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Rated output (kW) 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 *1 37 *1 45 *1 55
Rated current (A) 8.5 11.5 17.6 28.5 37.5 54 72.8 88 102 126 168 198 264
Rated torque (N·m)
9.55 14.1 23.6 35.0 47.7 70.0 95.5 118 140 191 235 286 350
Maximum torque 150% 60 s
(N
·m)
14.3 21.1 35.4 52.4 71.6 105 143 176 211 287 353 429 525
Rated speed (r/min) 1500
Maximum speed (r/min) 3000 *2 2400
Frame No. 90L 100L 112M 132S 132M 160M 160L 180M 180M 200L 200L 200L 225S
Inertia moment J (10
-4
kg·m
2
)
67.5 105 175 275 400 750 875 1725 1875 3250 3625 3625 6850
Noise *5 75 dB or less 80 dB or less
85 dB
or less
Cooling fan
(with thermal
protector)
*7*8
Voltage
Single-phase 200 V/50 Hz
Single-phase 200 V to 230 V/60 Hz
Three-phase 200 V/50 Hz
Three-phase 200 to 230 V/60 Hz
Input *3
36/55 W
(0.26/0.32 A)
22/28 W
(0.11/0.13 A)
55/71 W
(0.39/0.39 A)
100/156 W
(0.47/0.53 A)
85/130 W
(0.46/0.52 A)
Recommended
thermal setting
0.36 A 0.18 A 0.51 A 0.69 A 0.68 A
Surrounding air temperature,
humidity
-10 to +40°C (non-freezing), 90%RH or less (non-condensing)
Structure (Protective structure) Totally enclosed forced draft system (Motor: IP44, cooling fan: IP23S) *4
Detector Encoder 2048P/R, A phase, B phase, Z phase +12 VDC power supply *6
Equipment Encoder, thermal protector, fan
Heat resistance class F
Vibration rank V10
Approx. mass (kg) 24 33 41 52 62 99 113 138 160 238 255 255 320
400V class
Motor type
SF-V5RUH[ ]K
1235711151822303745 55
Applicable inverter model
FR-A840-[ ]K (ND rating)
2.2 2.2 3.7 7.5 11 15 18.5 22 30 37 45 55 75
Rated output (kW) 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 *1 37 *1 45 *1 55
Rated current (A) 4.2 5.8 8.8 14.5 18.5 27.5 35.5 44 51 67 84 99 132
Rated torque (N·m)
9.55 14.1 23.6 35.0
47.7 70.0 95.5 118 140 191 235 286 350
Maximum torque 150% 60 s (N·m)
14.3 21.1 35.4 52.4 71.6 105 143 176 211 287 353 429 525
Rated speed (r/min) 1500
Maximum speed (r/min) 3000 *2 2400
Frame No. 90L 100L 112M 132S 132M 160M 160L 180M 180M 200L 200L 200L 225S
Inertia moment J (10
-4
kg·m
2
)
67.5 105 175 275 400 750 875 1725 1875 3250 3625 3625 6850
Noise *5 75 dB or less 80 dB or less 85 dB or less
Cooling fan
(with thermal
protector)
*7*8
Voltage
Single-phase 200 V/50 Hz
Single-phase 200 V to 230 V/60 Hz
Three-phase 380 to 400 V/50 Hz
Three-phase 400 to 460 V/60 Hz
Input *3
36/55 W
(0.26/0.32 A)
22/28 W
(0.11/0.13 A)
55/71 W
(0.19/0.19 A)
100/156 W
(0.27/0.30 A)
85/130 W
(0.23/0.26 A)
Recommended
thermal setting
0.36 A 0.18 A 0.25 A 0.39 A 0.34 A
Surrounding air temperature,
humidity
-10 to +40°C (non-freezing), 90%RH or less (non-condensing)
Structure (Protective structure) Totally enclosed forced draft system (Motor: IP44, cooling fan: IP23S) *4
Detector Encoder 2048P/R, A phase, B phase, Z phase +12 VDC power supply *6
Equipment Encoder, thermal protector, fan
Heat resistance class F
Vibration rank V10
Approx. mass (kg) 24 33 41 52 62 99 113 138 160 238 255 255 320
