Mitsubishi FR-A800

BCN-C22005-696
Brakeoperationselectionforvectorcontrol(Pr.1299)
• The brake operation of the second motor can be selected under vector control or PM sensorless vector control.
Turning ON the RT signal enables the second pre-excitation selection (when Pr.450  "9999").
NOTE
• For the details of the pre-excitation operation, refer to page 609 of the Instruction Manual (Detailed).
Position loop gain (Pr.1298)
• The position loop gain can be set for the second motor under vector control or PM sensorless vector control.
Turning ON the RT signal validates the second position loop gain (when Pr.450  "9999").
NOTE
• For the details of the position loop gain, refer to page 251 of the Instruction Manual (Detailed).
Pulse monitor selection (Pr.430)
• The current position 2 can be selected for the pulse monitor selection.
 Accumulated value of estimated feedback pulses when PM sensorless vector control is used
• The following can be monitored with the PLC function special register.
Pr. Name
Initial
value
Setting
range
Description
1299
G108
Second pre-excitation
selection
0
0 Zero speed control The pre-excitation
operation of the second
motor can be selected.
1Servo lock
Pr. Name
Initial
value
Setting
range
Description
1298
B013
Second position control
gain
25 s
-1
0 to 150 s
-1
Set the position loop gain for the second motor.
Pr.430
setting
Description
[][][]0
Pulse monitor
selection
Displays the lower of the position command (accumulated value of command pulses).
[][][]1
Displays the upper of the position command (accumulated value of command pulses).
[][][]2
Displays the lower of the current position (accumulated value of feedback pulses).
[][][]3
Displays the upper of the current position (accumulated value of feedback pulses).
[][][]4
Displays the lower of the accumulated value of droop pulses.
[][][]5
Displays the upper of the accumulated value of droop pulses.
[][]12
Displays the lower of the current position 2 (accumulated value of feedback pulses).
[][]13
Displays the upper of the current position 2 (accumulated value of feedback pulses).
[]0[][]
For pulse monitor
selection
Displays the monitor item selected in the pulse monitor selection after the electronic gear operation.
[]1[][]
Displays the monitor item selected in the pulse monitor selection before the electronic gear operation.
0[][][]
For the multifunction
monitor /
For the PLC function
special register
Displays the monitor item selected in the multifunction monitor (position command, current position,
and droop pulse) before the electronic gear operation.
Displays the item in the PLC function special register (position command, current position, droop
pulse, and current position 2) before the electronic gear operation.
1[][][]
Displays the monitor item selected in the multifunction monitor (position command, current position,
and droop pulse) after the electronic gear operation.
Displays the item in the PLC function special register (position command, current position, droop
pulse, and current position 2) after the electronic gear operation.
8888
Output frequency
display
Displays the monitor item selected in the multifunction monitor (position command, current position,
and droop pulse) after the electronic gear operation.
Displays the item in the PLC function special register (position command, current position, droop
pulse, and current position 2) after the electronic gear operation.
9999
(initial
value)
Displays the monitor item selected in the multifunction monitor (position command, current position,
and droop pulse) before the electronic gear operation.
Displays the item in the PLC function special register (position command, current position, droop
pulse, and current position 2) before the electronic gear operation.
Device
number
Name Description
SD1209 Current position 2 (lower 16 bits) Stores the lower 16 bits of the current position 2 value.
SD1210 Current position 2 (upper 16 bits) Stores the upper 16 bits of the current position 2 value.
