Perform secure wiring.
(page 33)
Set the operation command. (Refer to page 306.)
Set the torque limit. (Pr.810)
(Refer to page 185.)
Perform offline auto tuning. (Pr.96)
(Refer to page 442.)
Select the control method. (Pr.800)
(Refer to page 164.)
As required
• Select online auto tuning. (Pr.95) (Refer to page 460.)
• Easy gain tuning (Refer to page 194.)
• Adjusting the speed control gain manually (Refer to page 195.)
Select Pr.800="10" (speed control) or "12" (speed/torque switchover) to
enable speed control.
Select the start command and speed command.
Set the motor capacity (kW) in Pr.80 Motor capacity, and set the number of
motor poles in Pr.81 Number of motor poles. (V/F control is performed
when the setting is "9999" (initial value).)
Set Pr.71 Applied motor to "3" (standard motor) or "13" (constant-torque
motor).
Set the overheat protection of the motor. (Pr.9)
(Refer to page 331.)
Set the rated motor current (A) in Pr.9 Electronic thermal O/L relay.
Set the motor capacity and number of motor poles.
(Pr.80, Pr.81) (Refer to page 164.)
Set the motor. (Pr.71)
(Refer to page 438.)
Set the rated motor voltage and the rated motor
frequency. (Pr.83, Pr.84) (Refer to page 442.)
Set the rated motor voltage (V) in Pr.83 Rated motor voltage, and set the
rated motor frequency (Hz) in Pr.84 Rated motor frequency.
Test run
