5.9.1 Operation mode selection
The following table lists valid and invalid commands in each operation mode.
 The priority of frequency commands when Pr.79 = "3" is "multi-speed operation (RL/RM/RH/REX) > PID control (X14) > terminal 4 analog input
(AU) > digital input by operation panel".
Select the operation mode of the inverter.
The mode can be changed among operations using external signals (External operation), operation by the operation
panel or the parameter unit (PU operation), combined operation of PU operation and External operation (External/PU
combined operation), and Network operation (when RS-485 terminals or a communication option is used).
Pr. Name Initial value Setting range Description
79
D000
Operation mode selection
0 0 to 4, 6, 7 Selects the operation mode.
Pr.79
setting
Description
LED display
:OFF
:ON
Refer
to
page
0
(initial
value)
Use the External/PU switchover mode ( ) to switch between the PU and External
operation mode.
At power ON, the inverter is in the External operation mode.
PU operation mode
External
operation mode
NET operation
mode
310
Operation mode Frequency command Start command
1 PU operation mode fixed
Operation panel or
parameter unit
or on
operation panel or
parameter unit
PU operation
mode
310
2
External operation mode
fixed.
The operation can be
performed by switching
between the External and
NET operation modes.
External signal input
(terminal 2 and 4, JOG,
multi-speed selection, etc.)
External signal input
(terminal STF, STR)
External
operation mode
NET operation
mode
310
3
External/PU combined
operation mode 1
Operation panel/
parameter unit or
external signal input
(multi-speed setting, terminal 4)

External signal input
(terminal STF, STR)
External/PU
combined
operation mode
311
4
External/PU combined
operation mode 2
External signal input
(terminal 2 and 4, JOG,
multi-speed selection, etc.)
or on
operation panel or
parameter unit
311
6
Switchover mode
Switching of PU, External, and NET operation modes can be performed during operation.
PU operation mode
External
operation mode
NET operation
mode
311
7
External operation mode (PU operation interlock)
X12 signal ON: Switchover to PU operation mode enabled (during External operation, output
shutoff)
X12 signal OFF: Switchover to PU operation mode disabled
