Mitsubishi FR-A800

Control method
PARAMETERS
167
5
2) Output terminal function selection (Pr.190 to Pr.196)
• Electronic thermal O/L relay pre-alarm (THP)
• Brake opening request (BOF)
• Second brake opening request (BOF2)
• Orientation complete (ORA)
• Orientation fault (ORM)
• Regenerative status output (Y32)
• In-position (Y36)
• Travel completed (MEND)
• Start time tuning completion (Y39)
• Home position return failure (ZA)
• Position detection level (FP)
• During position command opeartion (PBSY)
• Home position return completed (ZP)
???????
Parameters referred to
Pr.178 to Pr.189 (input terminal function selection) page 430
Pr.190 to Pr.196 (output terminal function selection) page 384
Valid/invalid status of monitor outputs during the test run
 : Valid
 : Invalid (always displays 0)
 : Displays accumulated value before the test
 : Not monitored
???????
Parameters referred to
Pr.52 Operation panel main monitor selection page 359
Pr.158 AM terminal function selection page 369
 Different output interface (operation panel, parameter
unit, terminal FM/CA or terminal AM) can output different
monitored items. For details, refer to page 369.
 When the operation is switched to the test run, "0" is
displayed. When PM sensorless vector control is selected
again after a test run, the output current peak value and
the electronic thermal relay load factor from the last
operation are displayed.
 The monitored status can be output via the terminal AM
only.
 When the operation is switched to the test run,
accumulated thermal value is reduced by considering the
output current is "0".
Types of monitor
DU/PU
Monitor
display
FM/AM/CA
Output
Output frequency 
Fault display  
Frequency setting value 
Running speed 
Converter output voltage 
Electric thermal relay load factor 
  
Output current peak value    
Converter output voltage peak
value

Load meter 
Cumulative energization time  
Reference voltage output  
Actual operation time  
Cumulative power 
Trace status  
Station number
(RS-485 terminals)
 
Station number (PU connector)  
Station number (CC-Link)  
Energy saving effect 
Cumulative energy saving 
PID set point 
PID measured value 
PID deviation 

Input terminal status  
Output terminal status  
Option input terminal status  
Option output terminal status  
Motor thermal load factor 
 
Inverter thermal load factor  
PTC thermistor value  
PID measured value 2 
Remote output 1 
Remote output 2 
Remote output 3 
Remote output 4 
PID manipulated amount 

Second PID set point 
Second PID measured value 
Second PID deviation 

Second PID measured value 2 
Second PID manipulated amount 

Dancer main speed setting 
Types of monitor
DU/PU
Monitor
display
FM/AM/CA
Output
