Mitsubishi FR-A800

Connection of motor with encoder (vector control)
INSTALLATION AND WIRING
69
2
• When using the inverter with the SF-V5RU (1500 r/min series), refer to the table below to set Pr.83 Rated motor voltage
and Pr.84 Rated motor frequency. For the setting of the SF-V5RU1, 3, and 4, refer to page 442.
• When using the inverter with the SF-V5RU1, SF-V5RU3, or SF-V5RU4, refer to the table below to set Pr.83 Rated motor
voltage and Pr.84 Rated motor frequency.
Combination with the vector control dedicated motor
When using the inverter with a vector control dedicated motor, refer to the table below.
• Combination with the SF-V5RU and SF-THY (ND rating)
Motor
capacity
SF-V5RU
Motor
capacity
SF-V5RU
200 V 400 V 200 V 400 V
Pr.83 (V) Pr.84 (Hz) Pr.83 (V) Pr.84 (Hz) Pr.83 (V) Pr.84 (Hz) Pr.83 (V) Pr.84 (Hz)
1.5 kW 188 52 345 52 18.5 kW 171 51 346 51
2.2 kW 188 52 360 52 22 kW 160 51 336 51
3.7 kW 190 52 363 52 30 kW 178 51 328 51
5.5 kW 165 51 322 51 37 kW 166 51 332 51
7.5 kW 164 51 331 51 45 kW 171 51 342 51
11 kW 171 51 320 51 55 kW 159 51 317 51
15 kW 164 51 330 51
Motor model
Pr.83 setting
Pr.84 setting
200 V class 400 V class
SF-V5RU1-30kW or lower 160 V 320 V
33.33 Hz
SF-V5RU1-37kW 170 V 340 V
SF-V5RU3-22kW or lower 160 V 320 V
SF-V5RU3-30kW 170 V 340 V
SF-V5RU4-3.7kW and 7.5kW 150 V 300 V
16.67 Hz
SF-V5RU4 and motors other
than described above
160 V 320 V
Voltage 200 V class 400 V class
Rated speed 1500 r/min
Base frequency 50 Hz
Maximum speed 3000 r/min
Motor capacity
Motor
frame
number
Motor model
Inverter model
FR-A820-[]
Motor
frame
number
Motor model
Inverter model
FR-A840-[]
1.5 kW 90L SF-V5RU1K 00167(2.2K) 90L SF-V5RUH1K 00083(2.2K)
2.2 kW 100L SF-V5RU2K 00250(3.7K) 100L SF-V5RUH2K 00083(2.2K)
3.7 kW 112M SF-V5RU3K 00340(5.5K) 112M SF-V5RUH3K 00126(3.7K)
5.5 kW 132S SF-V5RU5K 00490(7.5K) 132S SF-V5RUH5K 00250(7.5K)
7.5 kW 132M SF-V5RU7K 00630(11K) 132M SF-V5RUH7K 00310(11K)
11 kW 160M SF-V5RU11K 00770(15K) 160M SF-V5RUH11K 00380(15K)
15 kW 160L SF-V5RU15K 00930(18.5K) 160L SF-V5RUH15K 00470(18.5K)
18.5 kW 180M SF-V5RU18K 01250(22K) 180M SF-V5RUH18K 00620(22K)
22 kW 180M SF-V5RU22K 01540(30K) 180M SF-V5RUH22K 00770(30K)
30 kW 200L
 SF-V5RU30K 01870(37K) 200L SF-V5RUH30K 00930(37K)
37 kW 200L
 SF-V5RU37K 02330(45K) 200L SF-V5RUH37K 01160(45K)
45 kW 200L
 SF-V5RU45K 03160(55K) 200L SF-V5RUH45K 01800(55K)
55 kW 225S
 SF-V5RU55K 03800(75K) 225S SF-V5RUH55K 02160(75K)
75 kW 250MD SF-THY 04750(90K) 250MD SF-THY 02600(90K)
90 kW   250MD SF-THY 03250(110K)
110 kW   280MD SF-THY 03610(132K)
132 kW   280MD SF-THY 04320(160K)
160 kW   280MD SF-THY 04810(185K)
200 kW   280L SF-THY 05470(220K)
250 kW   315H SF-THY 06830(280K)
