(N) Operation via communication and its settings
PARAMETERS
589
5
GROUP
N
Modbus register
• System environmental variables
Communication parameter settings are not cleared.
At a write, the data is set as the control input command.
At a read, the data is read as the inverter running status.
At a write, the data is set as the operation mode setting.
At a read, the data is read as the operation mode setting.
<Inverter status/control input command>
The signal within parentheses ( ) is the initial status. The description changes depending on the setting of Pr.180 to Pr.189 (input terminal
function selection) (page 430).
For each of the assigned signals, some signals are enabled by NET and some are disabled. (Refer to page 321.)
The inverter run enable signal is in the initial status for the separated converter type.
The signal within parentheses ( ) is the initial status. The description changes depending on the setting of Pr.190 to Pr.196 (output terminal
function selection) (page 384).
No function is assigned in the initial status for the separated converter type.
<Operation mode/inverter setting>
Enable/disable parameter writing by Pr.79 and Pr.340 settings. For the details, refer to page 315.
Restrictions in each operation mode conform with the computer link specification.
Register Definition Read/Write Remarks
40002 Inverter reset Write Any value can be written
40003 Parameter clear Write Set H965A for the write value.
40004 All parameter clear Write Set H99AA for the write value.
40006 Parameter clear
Write Set H5A96 for the write value.
40007 All parameter clear
Write Set HAA99 for the write value.
40009 Inverter status/control input command
Read/Write Refer to the following.
40010 Operation mode/inverter setting
Read/Write Refer to the following.
40014 Running frequency (RAM value) Read/Write
The display can be changed to the rotations
per minute using Pr.37, Pr.144 and Pr.811.
(Refer to page 357)
40015 Running frequency (EEPROM value) Write
Bit
Definition
Control input command Inverter status
0 Stop command RUN (Inverter running)
1 Forward rotation command During forward rotation
2 Reverse rotation command During reverse rotation
3
RH (High-speed operation
command)
SU (Up to frequency)
4
RM (Middle-speed operation
command)
OL (Overload warning)
5
RL (Low-speed operation
command)
IPF (Instantaneous power failure/
undervoltage)
6 JOG (Jog operation selection)
FU (Output frequency detection)
7 RT (Second function selection) ABC1 (Fault)
8 AU (Terminal 4 input selection) ABC2 (-)
9
CS (Selection of automatic restart
after instantaneous power failure,
flying start)
Safety monitor output
10 MRS (Output stop) 0
11
STP (STOP) (Start self-holding
selection)
0
12 RES (Inverter reset) 0
13 0 0
14 0 0
15 0 Fault occurrence
Mode Read value
Write
value
EXT H0000 H0010
PU H0001 H0011
EXT
JOG
H0002
PU
JOG
H0003
NET H0004 H0014
PU+EXT H0005
