Mitsubishi FR-A800

(M) Monitor display and monitor output signal
356
PARAMETERS
5.11 (M) Monitor display and monitor output
signal
Purpose Parameter to set
Refer to
page
To display the motor speed.
To set to rotations per minute.
Speed display and
rotations per minute
setting
P. M 0 0 0 t o P. M 0 0 2 ,
P.D030
Pr.37, Pr.144,
Pr.505, Pr.811
357
To change the monitored item on
the operation panel and parameter
unit
Operation panel
monitored item
selection,
clearing the cumulative
monitor
P. M 0 2 0 t o P. M 0 2 3 ,
P.M030, P.M031,
P.M044,
P.M050 to P.M052,
P.M100 to P.M104
Pr.52, Pr.170,
Pr.171, Pr.268,
Pr.290, Pr.563,
Pr.564,
Pr.774 to Pr.776,
Pr.891, Pr.992
Pr.1106 to
Pr.1108
359
To change the monitored item
output from the terminal FM(CA)
and AM
Terminal FM(CA)
function selection
P. M 0 4 0 t o P. M 0 4 2 ,
P.M044, P.M300,
P.M301, P.D100
Pr.54, Pr.55,
Pr.56, Pr.158,
Pr.290, Pr.291,
Pr.866
369
To adjusting the terminal FM,
terminal CA, and AM output
Terminal FM(CA), AM
calibration
P.M310, P.M320,
P.M321,
P.M330 to P.M334
Pr.867, Pr.869,
C0(Pr.900),
C1(Pr.901),
C8(Pr.930) to
C11(Pr.931)
375
To check the effects of energy
saving
Energy saving monitor
P.M023, P.M100,
P. M 2 0 0 t o P. M 2 0 7 ,
P.M300, P.M301
Pr.52, Pr.54,
Pr.158, Pr.891 to
Pr.899
379
To assign functions to the output
terminals
Output terminal function
assignment
P. M 4 0 0 t o P. M 4 0 6 ,
P. M4 31
Pr.190 to Pr.196,
Pr.289
384
To detect the output frequency
Up-to-frequency
sensitivity
Output frequency
detection
Low speed detection
P.M440 to P.M446
Pr.41 to Pr.43,
Pr.50, Pr.116,
Pr.865, Pr.870
392
To detect the output current
Output current detection
Zero current detection
P.M460 to P.M464
Pr.150 to Pr.153,
Pr.166, Pr.167
395
To detecting the output torque Output torque detection P.M470 Pr.864 397
To use the remote output function Remote output P.M500 to P.M502 Pr.495 to Pr.497 398
To use the analog remote output
function
Analog remote output P.M530 to P.M534 Pr.655 to Pr.659 400
To output the fault code from a
terminal
Fault code output
function
P. M5 10 P r. 76 402
T
o de
tect the specified output
power
Pulse train output of
output power
P.M520 Pr.799 403
To detect the control circuit
temperature
Control circuit
temperature monitor
P.M060 Pr.663 404
