(F) Setting of acceleration/deceleration time and acceleration/deceleration pattern
304
PARAMETERS
Lift operation adjustment (Pr.61, Pr.64)
• The application range can be expanded by setting the parameters for adjustment of Pr.61 and Pr.64.
The setting range for the FR-A820-03160(55K) or lower and FR-A840-01800(55K) or lower.
The setting range for the FR-A820-03800(75K) or higher and FR-A840-02160(75K) or higher.
NOTE
• Even if the lift operation has been selected, inputting the JOG signal (Jog operation), RT signal (second function selection) or
X9 signal (third function selection) during an inverter stop will disable the automatic acceleration/deceleration and give priority
to JOG operation, second function selection or third function selection. Note that during operation, an input of JOG and RT
signal does not have any influence even when the automatic acceleration/deceleration is enabled.
• Even if Pr.61 and Pr.64 are set, changing Pr.292 automatically resets to the initial setting (9999). Set Pr.61 and Pr.64 after
setting Pr.292.
Pr.0 Torque boost page 597
Pr.13 Starting frequency page 298
Pr.14 Load pattern selection page 600
Pr.19 Base frequency voltage page 598
Pr.2 Stall prevention operation level page 348
Pr.570 Multiple rating setting page 265
Pr. Name Setting range Description
61
Reference current
0 to 500 A Set the rated motor current value when the motor capacity and inverter
capacity differ, etc. Set the reference current (A) of the stall prevention
operation level.
0 to 3600 A
9999 (initial value) The rated inverter output current value is the reference.
64
Starting
frequency for
elevator mode
0 to 10 Hz Set the starting frequency for the lift operation.
9999 (initial value) Starting frequency is 2 Hz.
