Parameter list (by parameter number)
122
PARAMETERS
5.1 Parameter List
5.1.1 Parameter list (by parameter number)
For simple variable-speed operation of the inverter, the initial value of the parameters may be used as they are. Set the necessary
parameters to meet the load and operational specifications. Parameter setting, change and check can be made from the operation panel (FR-
DU08).
NOTE
• indicates simple mode parameters. Use Pr.160 User group read selection to indicate the simple mode
parameters only.
• Parameter setting may be restricted in some operating statuses. Use Pr.77 Parameter write selection to change the setting.
• Refer to Appendix 3 (page 711) for instruction codes for communication and availability of parameter clear, all clear, and
parameter copy of each parameter.
Function
Pr.
Pr.
group
Name Setting range
Minimum
setting
increments
Initial value
Refer
to
page
Customer
setting
FM CA
Basic functions
0G000
Torque boost
0 to 30% 0.1%
6%

597
4%

3% 
2% 
1% 
1H400
Maximum frequency
0 to 120 Hz 0.01 Hz
120 Hz

345
60 Hz

2H401
Minimum frequency
0 to 120 Hz 0.01 Hz 0 Hz 345
3G001
Base frequency
0 to 590 Hz 0.01 Hz 60 Hz 50 Hz 598
4D301
Multi-speed setting (high speed)
0 to 590 Hz 0.01 Hz 60 Hz 50 Hz 328
5D302
Multi-speed setting (middle speed)
0 to 590 Hz 0.01 Hz 30 Hz 328
6D303
Multi-speed setting (low speed)
0 to 590 Hz 0.01 Hz 10 Hz 328
7 F010
Acceleration time
0 to 3600 s 0.1 s
5 s

285
15 s

8F011
Deceleration time
0 to 3600 s 0.1 s
5 s

285
15 s

9
H000
C103
Electronic thermal O/L relay
Rated motor current
0 to 500 A 0.01 A

Rated inverter
current
331,
442,
452
0 to 3600 A 0.1 A

DC injection
brake
10 G100
DC injection brake operation
frequency
0 to 120 Hz, 9999 0.01 Hz 3 Hz 605
11 G101
DC injection brake operation time 0 to 10 s, 8888 0.1 s 0.5 s 605
12 G110
DC injection brake operation
voltage
0 to 30% 0.1%
4%

6052% 
1% 

13 F102
Starting frequency 0 to 60 Hz 0.01 Hz 0.5 Hz
298,
299

14 G003
Load pattern selection 0 to 5 1 0 600
Jog
operation
15 D200
Jog frequency 0 to 590 Hz 0.01 Hz 5 Hz 327
16 F002
Jog acceleration/deceleration time 0 to 3600 s 0.1 s 0.5 s 327

17 T720
MRS input selection 0, 2, 4 1 0 433

18 H402
High speed maximum frequency 0 to 590 Hz 0.01 Hz
120 Hz

345
60 Hz


19 G002
Base frequency voltage
0 to 1000 V, 8888,
9999
0.1 V 9999 8888 598
