Mitsubishi FR-A800

Parameter List
Parameter list (by parameter number)
PARAMETERS
123
Pr.
List
5
Acceleration/
deceleration
times
20 F000
Acceleration/deceleration reference
frequency
1 to 590 Hz 0.01 Hz 60 Hz 50 Hz 285
21 F001
Acceleration/deceleration time
increments
0, 1 1 0 285
Stall
prevention
22 H500
Stall prevention operation level
(Torque limit level)
0 to 400% 0.1% 150%
185,
348
23 H610
Stall prevention operation level
compensation factor at double
speed
0 to 200%, 9999 0.1% 9999 348
Multi-speed
setting
24 to
27
D304
to
D307
Multi-speed setting (4 speed to 7
speed)
0 to 590 Hz, 9999 0.01 Hz 9999 328

28 D300
Multi-speed input compensation
selection
0, 1 1 0 328

29 F100
Acceleration/deceleration pattern
selection
0 to 6 1 0 290

30 E300
Regenerative function selection
0 to 2, 10, 11, 20, 21,
100 to 102, 110, 111,
120, 121

10
6142, 10, 11, 102, 110,
111

110
0, 2, 10, 20, 100, 102,
110, 120

10
Frequency
jump
31 H420
Frequency jump 1A 0 to 590 Hz, 9999 0.01 Hz 9999 346
32 H421
Frequency jump 1B 0 to 590 Hz, 9999 0.01 Hz 9999 346
33 H422
Frequency jump 2A 0 to 590 Hz, 9999 0.01 Hz 9999 346
34 H423
Frequency jump 2B 0 to 590 Hz, 9999 0.01 Hz 9999 346
35 H424
Frequency jump 3A 0 to 590 Hz, 9999 0.01 Hz 9999 346
36 H425
Frequency jump 3B 0 to 590 Hz, 9999 0.01 Hz 9999 346

37 M000
Speed display 0, 1 to 9998 1 0 357
Frequency
detection
41 M441
Up-to-frequency sensitivity 0 to 100% 0.1% 10% 392
42 M442
Output frequency detection 0 to 590 Hz 0.01 Hz 6 Hz 392
43 M443
Output frequency detection for
reverse rotation
0 to 590 Hz, 9999 0.01 Hz 9999 392
Second functions
44 F020
Second acceleration/deceleration
time
0 to 3600 s 0.1 s 5 s
285,
521
45 F021
Second deceleration time 0 to 3600 s, 9999 0.1 s 9999
285,
521
46 G010
Second torque boost 0 to 30%, 9999 0.1% 9999 597
47 G011
Second V/F (base frequency) 0 to 590 Hz, 9999 0.01 Hz 9999 598
48 H600
Second stall prevention operation
level
0 to 400% 0.1% 150% 348
49 H601
Second stall prevention operation
frequency
0 to 590 Hz, 9999 0.01 Hz 0 Hz 348
50 M444
Second output frequency detection 0 to 590 Hz 0.01 Hz 30 Hz 392
51
H010
C203
Second electronic thermal O/L relay
Rated second motor current
0 to 500 A, 9999
 0.01 A
9999
331,
442,
452
0 to 3600 A, 9999
 0.1 A
Function
Pr.
Pr.
group
Name Setting range
Minimum
setting
increments
Initial value
Refer
to
page
Customer
setting
FM CA
