Mitsubishi FR-A800

Parameter List
Parameter list (by function group)
PARAMETERS
151
5
 M: Monitor display and monitor output signal
Parameters regarding the inverter's operating status. These
parameters are used to set the monitors and output signals.
 T: Multi-function input terminal parameters
Parameters for the input terminals where inverter commands are
received through.
Pr.
group
Pr. Name
Refer
to page
M000 37
Speed display
357
M001 505
Speed setting reference
357
M002 144
Speed setting switchover
357
M020 170
Watt-hour meter clear
359
M021 563
Energization time carrying-over times
359
M022 268
Monitor decimal digits selection
359
M023 891
Cumulative power monitor digit shifted
times
359,
379
M030 171
Operation hour meter clear
359
M031 564
Operating time carrying-over times
359
M040 55
Frequency monitoring reference
369
M041 56
Current monitoring reference
369
M042 866
Torque monitoring reference
369
M043 241
Analog input display unit switchover
415
M044 290
Monitor negative output selection
359,
369
M050 1106
Torque monitor filter
359
M051 1107
Running speed monitor filter
359
M052 1108
Excitation current monitor filter
359
M060 663
Control circuit temperature signal
output level
404
M100 52
Operation panel main monitor selection
359
M101 774
Operation panel monitor selection 1
359
M102 775
Operation panel monitor selection 2
359
M103 776
Operation panel monitor selection 3
359
M104 992
Operation panel setting dial push
monitor selection
359
M200 892
Load factor
379
M201 893
Energy saving monitor reference (motor
capacity)
379
M202 894
Control selection during commercial
power-supply operation
379
M203 895
Power saving rate reference value
379
M204 896
Power unit cost
379
M205 897
Power saving monitor average time
379
M206 898
Power saving cumulative monitor clear
379
M207 899
Operation time rate (estimated value)
379
M300 54
FM/CA terminal function selection
369
M301 158
AM terminal function selection
369
M310
C0
(900)

FM/CA terminal calibration
375
M320
C1
(901)

AM terminal calibration
375
M321 867
AM output filter
375
M330
C8
(930)

Current output bias signal
375
M331
C9
(930)

Current output bias current
375
M332
C10
(931)

Current output gain signal
375
M333
C11
(931)

Current output gain current
375
M334 869
Current output filter
375
M400 190
RUN terminal function selection
384
M401 191
SU terminal function selection
384
M402 192
IPF terminal function selection
384
M403 193
OL terminal function selection
384
M404 194
FU terminal function selection
384
M405 195
ABC1 terminal function selection
384
M406 196
ABC2 terminal function selection
384
M430 157
OL signal output timer
185,
348
M431 289
Inverter output terminal filter
384
M433 166
Output current detection signal
retention time
395
M440 870
Speed detection hysteresis
392
M441 41
Up-to-frequency sensitivity
392
M442 42
Output frequency detection
392
M443 43
Output frequency detection for reverse
rotation
392
M444 50
Second output frequency detection
392
M445 116
Third output frequency detection
392
M446 865
Low speed detection
392
M460 150
Output current detection level
395
M461 151
Output current detection signal delay
time
395
M462 152
Zero current detection level
395
M463 153
Zero current detection time
395
M464 167
Output current detection operation
selection
395
M470 864
Torque detection
397
M500 495
Remote output selection
398
M501 496
Remote output data 1
398
M502 497
Remote output data 2
398
M510 76
Fault code output selection
402
M520 799
Pulse increment setting for output
power
403
M530 655
Analog remote output selection
400
M531 656
Analog remote output 1
400
M532 657
Analog remote output 2
400
M533 658
Analog remote output 3
400
M534 659
Analog remote output 4
400
Pr.
group
Pr. Name
Refer
to page
T000 73
Analog input selection
406,
411
T001 267
Terminal 4 input selection
406
T002 74
Input filter time constant
413
T003 822
Speed setting filter 1
413
T004 826
Torque setting filter 1
413
T005 832
Speed setting filter 2
413
T006 836
Torque setting filter 2
413
T007 849
Analog input offset adjustment
413
T010 868
Terminal 1 function assignment
185,
348,
410
T021 242
Terminal 1 added compensation amount
(terminal 2)
411
T022 125
Terminal 2 frequency setting gain
frequency
415
T040 858
Terminal 4 function assignment
185,
348,
410
T041 243
Terminal 1 added compensation amount
(terminal 4)
411
Pr.
group
Pr. Name
Refer
to page
