Parameter List
Parameter list (by function group)
PARAMETERS
157
5
Setting can be made only when the FR-A8AP is mounted.
The parameter number in parentheses is the one for use with the LCD
operation panel and the parameter unit.
Setting can be made only for the standard model.
Setting can be made only for the standard model and the IP55 compatible
model.
The setting is available only with the 400 V class.
G001 3
Base frequency
598
G002 19
Base frequency voltage
598
G003 14
Load pattern selection
600
G010 46
Second torque boost
597
G011 47
Second V/F (base frequency)
598
G020 112
Third torque boost
597
G021 113
Third V/F (base frequency)
598
G030 60
Energy saving control selection
602
G040 100
V/F1 (first frequency)
603
G041 101
V/F1 (first frequency voltage)
603
G042 102
V/F2 (second frequency)
603
G043 103
V/F2 (second frequency voltage)
603
G044 104
V/F3 (third frequency)
603
G045 105
V/F3 (third frequency voltage)
603
G046 106
V/F4 (fourth frequency)
603
G047 107
V/F4 (fourth frequency voltage)
603
G048 108
V/F5 (fifth frequency)
603
G049 109
V/F5 (fifth frequency voltage)
603
G060 673
SF-PR slip amount adjustment
operation selection
604
G061 674
SF-PR slip amount adjustment gain
604
G100 10
DC injection brake operation frequency
605
G101 11
DC injection brake operation time
605
G102 802
Pre-excitation selection
605
G103 850
Brake operation selection
611
G105 522
Output stop frequency
611
G106 250
Stop selection
613
G107 70
Special regenerative brake duty
614
G110 12
DC injection brake operation voltage
605
G120 882
Regeneration avoidance operation
selection
621
G121 883
Regeneration avoidance operation level
621
G122 884
Regeneration avoidance at deceleration
detection sensitivity
621
G123 885
Regeneration avoidance compensation
frequency limit value
621
G124 886
Regeneration avoidance voltage gain
621
G125 665
Regeneration avoidance frequency gain
621
G130 660
Increased magnetic excitation
deceleration operation selection
624
G131 661
Magnetic excitation increase rate
624
G132 662
Increased magnetic excitation current
level
624
G200 800
Control method selection
164
G203 245
Rated slip
625
G204 246
Slip compensation time constant
625
G205 247
Constant-power range slip
compensation selection
625
G206 1116
Constant output range speed control P
gain compensation
192
G210 803
Constant output range torque
characteristic selection
185,
216
G211 820
Speed control P gain 1
192
G212 821
Speed control integral time 1
192
G213 824
Torque control P gain 1 (current loop
proportional gain)
225,
255
G214 825
Torque control integral time 1 (current
loop integral time)
225,
255
G215 823
Speed detection filter 1
254
G216 827
Torque detection filter 1
254
G217 854
Excitation ratio
255
G218 1115
Speed control integral term clear time
192
G220 877
Speed feed forward control/model
adaptive speed control selection
200,
251
G221 878
Speed feed forward filter
200
Pr.
group
Pr. Name
Refer
to page
Simple
Simple
G222 879
Speed feed forward torque limit
200
G223 881
Speed feed forward gain
200
G224 828
Model speed control gain
200,
251
G230 840
Torque bias selection
202
G231 841
Torque bias 1
202
G232 842
Torque bias 2
202
G233 843
Torque bias 3
202
G234 844
Torque bias filter
202
G235 845
Torque bias operation time
202
G236 846
Torque bias balance compensation
202
G237 847
Fall-time torque bias terminal 1 bias
202
G238 848
Fall-time torque bias terminal 1 gain
202
G240 367
Speed feedback range
626
G241 368
Feedback gain
626
G250 788
Low speed range torque characteristic
selection
176
G260 1121
Per-unit speed control reference
frequency
192
G261 1117
Speed control P gain 1 (per-unit system)
192
G262 1119
Model speed control gain (per-unit
system)
200
G300 451
Second motor control method selection
164
G311 830
Speed control P gain 2
192
G312 831
Speed control integral time 2
192
G313 834
Torque control P gain 2
225
G314 835
Torque control integral time 2
225
G315 833
Speed detection filter 2
254
G316 837
Torque detection filter 2
254
G350 747
Second motor low-speed range torque
characteristic selection
176
G361 1118
Speed control P gain 2 (per-unit system)
192
G400 286
Droop gain
628
G401 287
Droop filter time constant
628
G402 288
Droop function activation selection
628
G403 994
Droop break point gain
628
G404 995
Droop break point torque
628
G410 653
Speed smoothing control
630
G411 654
Speed smoothing cutoff frequency
630
G601 1003
Notch filter frequency
208
G602 1004
Notch filter depth
208
G603 1005
Notch filter width
208
G932 89
Speed control gain (Advanced magnetic
flux vector)
170
G942 569
Second motor speed control gain
170
Pr.
group
Pr. Name
Refer
to page
