Mitsubishi FR-A800

Position control under vector control and PM sensorless vector control
246
PARAMETERS
Pulse monitor selection (Pr.430)
• Shows the various pulse conditions during operation as the number of pulses. Set "0" in Pr.52 Operation panel main
monitor selection to display the output frequency monitor.
• If any of "26 to 31" is set in Pr.52, Pr.774 to Pr.776, and Pr.992, the electronic gear operation setting for the pulse monitor
by the multifunction monitor can be changed. (Refer to page 359)
 Accumulated value of estimated feedback pulses when PM sensorless vector control is used
The pulse monitor of the operation panel (FR-DU08)
• The position command, current position and the status of droop pulses can be displayed on the operation panel.
• If displayed data has signs, minus signs appear for both upper and lower digits.
• If -99999999 or 99999999 is exceeded on the pulse monitor, the monitor value is reset to 0.
NOTE
• The pulse count starts at servo on.
• The accumulated number of pulses is cleared at base shutoff or when the CLR signal is turned ON.
• Changing the terminal assignment using Pr.178 to Pr.189 (input terminal function selection) may affect the other
functions. Set parameters after confirming the function of each terminal.
???????
Parameters referred to
Pr.52 Operation panel main monitor selection page 359
Pr.178 to Pr.189 (input terminal function selection) page 430
Pr.430 setting Description
[][][]0
Pulse monitor selection
Displays the lower of the position command (accumulated value of command pulses).
[][][]1 Displays the upper of the position command (accumulated value of command pulses).
[][][]2 Displays the lower of the current position (accumulated value of feedback pulses
).
[][][]3 Displays the upper of the current position (accumulated value of feedback pulses
).
[][][]4 Displays the lower of the accumulated value of droop pulses.
[][][]5 Displays the upper of the accumulated value of droop pulses.
[]0[][]
For pulse monitor
selection
Displays the monitor item selected in the pulse monitor selection after the electronic gear
operation.
[]1[][]
Displays the monitor item selected in the pulse monitor selection before the electronic gear
operation.
0[][][]
For multifunction
monitor
Displays the monitor item selected in the multifunction monitor (position command, current
position, and droop pulse) before the electronic gear operation.
1[][][]
Displays the monitor item selected in the multifunction monitor (position command, current
position, and droop pulse) after the electronic gear operation.
8888
Output frequency
display
Displays the monitor item selected in the multifunction monitor (position command, current
position, and droop pulse) after the electronic gear operation.
9999 (initial value)
Displays the monitor item selected in the multifunction monitor (position command, current
position, and droop pulse) before the electronic gear operation.
Display data Monitor display without signs Monitor display with signs
-10000
Lower monitor
Upper monitor
-100
Lower monitor
Upper monitor
