Mitsubishi FR-A800

Motor rating
694
SPECIFICATIONS
IPM motor MM-CF (2000r/min series)
 When the power supply voltage drops, we cannot guarantee the above output and rated speed.
 When the load torque is 20% of the motor rating. The permissible load inertia moment ratio is smaller when the load torque is larger.
Consult us if the load inertia moment ratio exceeds the above value.
 This does not apply to the shaft through portion.
 Value for MM-CF[ ]2C.
 The value for MM-CF[ ]2B is indicated in parentheses.
 Applicable one-rank higher inverters for the lifted low-speed range torque operation. PM sensorless vector control specification
Motor type
MM-CF[ ]
52(C)(B) 102(C)(B) 152(C)(B) 202(C)(B) 352(C)(B) 502(C) 702(C)
Applicable
inverter
FR-A820[ ]K
SLD
0.4 0.4 0.75 1.5 2.2 3.7 5.5
LD
0.4 0.4 0.75 1.5 2.2 3.7 5.5
ND (initial setting)
0.4 0.75 1.5 2.2 3.7 5.5 7.5
HD
0.75 1.5 2.2 3.7 5.5 7.5 11
Continuous
characteristics

Rated output[kW]
0.5 1.0 1.5 2.0 3.5 5.0 7.0
Rated torque[N·m]
2.39 4.78 7.16 9.55 16.70 23.86 33.41
Rated speed[r/min]
2000
Max. speed [r/min]
3000
Instantaneous permissible speed [r/
min]
3450
Maximum torque [N·m]
4.78 9.56 14.32 19.09 33.41 47.73 66.82
Inertia moment J [×10
-4
kg·m
2
]
6.6
(7.0)
13.7
(14.9)
20.0
(21.2)
45.5
(48.9)
85.6
(89.0)
120.0 160.0
Recommended ratio of load inertia
moment to motor shaft inertia moment

100 times max. 50 times max.
Rated current [A]
1.81 3.70 5.22 7.70 12.5 20.5 27.0
Insulation rank
Class F
Structure
Totally-enclosed, self-cooling (protective system:IP44 , IP65 )
Surrounding air temperature, humidity
-10°C to +40°C (non-freezing), 90%RH or less (non-condensing)
Storage temperature and humidity
-20°C to +70°C (non-freezing), 90%RH or less (non-condensing)
Ambience
Indoors (no direct sunlight), free from corrosive gas, flammable gas, oil mist, dust and
dirt
Altitude
Max. 1000 m above sea level
Vibration
X: 9.8 m/s
2
, Y: 24.5 m/s
2
Mass [kg]
5.1 (7.8) 7.2 (11) 9.3 (13) 13 (20) 19 (28) 27 36
