Mitsubishi FR-A800

(E) Environment setting parameters
PARAMETERS
265
5
GROUP
E
5.7.10 Multiple rating setting
 Not compatible with the IP55 compatible model.
Changing the parameter initial values and setting ranges
• When inverter reset and all parameter clear are performed after setting Pr.570, the parameter initial values are changed
according to each rating, as shown below.
 Initial values differ depending on the rating as follows.
Four rating types of different rated current and permissible load can be selected. The optimal inverter rating can be
chosen in accordance with the application, enabling equipment size to be reduced.
Pr. Name Initial value
Setting
range
Description (overload current rating,
surrounding air temperature)
570
E301
Multiple rating setting
2
0

SLD rating
110% 60 s, 120% 3 s (inverse-time characteristics)
Surrounding air temperature 40°C
1
LD rating
120% 60 s, 150% 3 s (inverse-time characteristics)
Surrounding air temperature 50°C
2
ND rating
150% 60 s, 200% 3 s (inverse-time characteristics)
Surrounding air temperature 50°C
3

HD rating
200% 60 s, 250% 3 s (inverse-time characteristics)
Surrounding air temperature 50°C
Pr. Name
Pr.570 setting
Refer
to
0 1
2
(Initial value)
3
0 Torque boost     597
7 Acceleration time
    285
8 Deceleration time
    285
9 Electronic thermal O/L relay
SLD rated
current

LD rated
current

ND rated
current

HD rated
current

331
12 DC injection brake operation voltage
    605
22 Stall prevention operation level 110% 120% 150% 200% 185, 348
48 Second stall prevention operation level 110% 120% 150% 200% 348
56 Current monitoring reference
SLD rated
current

LD rated
current

ND rated
current

HD rated
current

369
114 Third stall prevention operation level 110% 120% 150% 200% 348
148 Stall prevention level at 0 V input 110% 120% 150% 200% 348
149 Stall prevention level at 10 V input 120% 150% 200% 250% 348
150 Output current detection level 110% 120% 150% 200% 395
165 Stall prevention operation level for restart 110% 120% 150% 200% 528
557
Current average value monitor signal
output reference current
SLD rated
current

LD rated
current

ND rated
current

HD rated
current

283
874 OLT level setting 110% 120% 150% 200% 185
893
Energy saving monitor reference (motor
capacity)
SLD rated motor
capacity

LD rated motor
capacity

ND rated motor
capacity

HD rated motor
capacity

379
