(E) Environment setting parameters
PARAMETERS
273
5
GROUP
E
• 3-line monitor setting
The 3-line monitor is used as the first monitor.
• Extended direct setting
Pressing the [FUNC] key of the FR-PU07-01 displays the extended direct setting screen. The PID action set point can be
directly set regardless of the operation mode or Pr.77 Parameter write selection setting.
Pressing the [FUNC] key on the extended direct setting screen displays the function menu.
• Dedicated parameter list function
Pressing the [PrSET] key of the FR-PU07-01 displays the dedicated parameter list. Parameters that need to be set first for
the PID extended display setting are listed.
NOTE
• The display of parameters other than the above may be changed due to changes in C42 or C44. Set the PID monitor
indicator before changing the settings of other parameters.
GOT initial setting (PU connector) (Pr.999 = "10, 12")
 When Pr.414="1", the setting value is not changed.
• Initial setting with the GOT2000 series
- When "FREQROL 500/700/800, SENSORLESS SERVO" is selected for "Controller Type" in the GOT setting, set
Pr.999="10" to configure the GOT initial setting.
- When "FREQROL 800(Automatic Negotiation)" is selected for "Controller Type" in the GOT setting, the GOT automatic
connection can be used. When "FREQROL 800(Automatic Negotiation)" is selected for "Controller Type" in the GOT
setting and the GOT automatic connection is not used, set Pr.999="12" to configure the GOT initial setting. (Refer to page
595)
• Initial setting with the GOT1000 series
-Set Pr.999="10" to configure the GOT initial setting.
NOTE
• Always perform an inverter reset after the initial setting.
• For the details of connection with GOT, refer to the Instruction Manual of GOT.
Extended direct setting Parameter to be set
Extended direct setting 1 Pr.133 PID action set point
Extended direct setting 2 Pr.755 Second PID action set point
Dedicated parameter list Parameter to be set
No.1 Pr.999 Automatic parameter setting
No.2 Pr.934 PID display bias coefficient
No.3 Pr.935 PID display gain coefficient
Pr. Name
Initial
value
Pr.999="10" Pr.999="12" Refer to page
79 Operation mode selection
01 1 306
118 PU communication speed
192 192 1152
563
119 PU communication stop bit length
110 0
120 PU communication parity check
21 1
121 Number of PU communication retries
1 9999 9999
122 PU communication check time interval
9999 9999 9999
123 PU communication waiting time setting
9999 0 ms 0 ms
124 PU communication CR/LF selection
11 1
340 Communication startup mode selection
00 0 315
414 PLC function operation selection
0— 2 545
