Mitsubishi FR-A800

APPENDIX
729
Appendix 4 For customers using HMS network
options
List of inverter monitored items
The following items can be set using a communication option.
16bit data
No. Description Unit Type
Read/
write
H0000 No data - - -
H0001 Output frequency 0.01Hz unsigned R
H0002 Output current 0.01A/0.1A unsigned R
H0003 Output voltage 0.1V unsigned R
H0004 reserved - - -
H0005 Frequency setting value 0.01Hz unsigned R
H0006 Motor speed 1r/min unsigned R
H0007 Motor torque 0.1% unsigned R
H0008 Converter output voltage 0.1V unsigned R
H0009 Regenerative brake duty 0.1% unsigned R
H000A
Electric thermal relay function
load factor
0.1% unsigned R
H000B Output current peak value 0.01A/0.1A unsigned R
H000C Converter output voltage peak value 0.1V unsigned R
H000D Input power 0.01kW/0.1kW unsigned R
H000E Output power 0.01kW/0.1kW unsigned R
H000F Input terminal status
 --R
H0010 Output terminal status
 --R
H0011 Load meter 0.1% unsigned R
H0012 Motor excitation current 0.01A/0.1A unsigned R
H0013 Position pulse 1 unsigned R/W
H0014 Cumulative energization time 1h unsigned R
H0015 reserved - - -
H0016 Orientation status 1 unsigned R
H0017 Actual operation time 1h unsigned R
H0018 Motor load factor 0.1% unsigned R
H0019 Cumulative power 1kWh unsigned R
H001A to
H001F
reserved - - -
H0020 Torque order 0.1% unsigned R
H0021 Torque current order 0.1% unsigned R
H0022 Motor output 0.1kW unsigend R
H0023 Feedback pulse 1 unsigned R
H0024 to
H002D
reserved - - -
H002E Motor temperature R
H002F to
H0031
reserved - - -
H0032 Power saving effect - unsigned R
H0033 Cumulative saving power - unsigned R
H0034 PID set point 0.1% unsigned R/W
H0035 PID measured value 0.1% unsigned R/W
H0036 PID deviation 0.1% unsigned R/W
H0037 to
H0039
reserved - - -
H003A Option input terminal status1
 --R
H003B Option input terminal status2
 --R
H003C Option output terminal status
 --R
H003D Motor thermal load factor 0.1% unsigned R
