Mitsubishi FR-A800

(C) Motor constant parameters
PARAMETERS
439
5
GROUP
C
Setting the applied motor
• Refer to the following list and set the parameters according to the applied motor.
 The setting is available for FR-A820-00630(11K) or lower.
 For the FR-A820-03160(55K) or lower and FR-A840-01800(55K) or lower.
 For the FR-A820-03800(75K) or higher and FR-A840-02160(75K) or higher.
 The same operation is performed for the both settings.
Pr.71 Pr.450 Motor
Constant value range when
performing offline auto tuning
(increment)
Operational characteristic of
the electronic thermal O/L
relay
Standard
Constant -
torque
PM
0
(Pr.71 initial
value)
Standard motor (such as SF-JR)
Pr.82(Pr.455) and Pr.859(Pr.860)
• 0 to 500 A, 9999 (0.01 A)

• 0 to 3600 A, 9999 (0.1 A)
Pr.90(Pr.458) and Pr.91(Pr.459)
• 0 to 50 , 9999 (0.001 )

• 0 to 400 m, 9999 (0.01 m)
Pr.92(Pr.460) and Pr.93(Pr.461)
(Induction motor)
• 0 to 6000 mH, 9999 (0.1 mH)

• 0 to 400 mH, 9999 (0.01 mH)
Pr.92(Pr.460) and Pr.93(Pr.461)
(PM motor)
• 0 to 500 mH, 9999 (0.01 mH)

• 0 to 50 mH, 9999 (0.001 mH)
Pr.94(Pr.462)
• 0 to 100%, 9999(0.1%)

• 0 to 100%, 9999(0.01%)
Pr.706(Pr.738)
• 0 to 5000 mV/(rad/s), 9999
(0.1 mV/(rad/s))

1
Constant-torque motor (SF-JRCA, etc.)
SF-V5RU (other than 1500 r/min series)

2 
Standard motor (such as SF-JR)
Adjustable 5 points V/F (Refer to page 603.)

20
Mitsubishi standard motor (SF-JR 4P 1.5
kW or lower)

30
Vector control dedicated motor
SF-V5RU (1500 r/min series)
SF-THY

40 Mitsubishi high-efficiency motor SF-HR 
50 Mitsubishi constant-torque motor SF-HRCA 
70
Mitsubishi high-performance energy-saving
motor SF-PR

330
 IPM motor MM-CF 
8090 IPM motor (other than MM-CF) 
9090 SPM motor 
3 (4)
 Standard motor (such as SF-JR)
Pr.82(Pr.455), Pr.859(Pr.860),
Pr.90(Pr.458), Pr.91(Pr.459),
Pr.92(Pr.460), Pr.93(Pr.461),
Pr.94(Pr.462) and Pr.706(Pr.738)
• Internal data value 0 to 65534, 9999 (1)
The display increment can be changed
in Pr.684.

13 (14)

Constant-torque motor (SF-JRCA, etc.)
SF-V5RU (other than 1500 r/min series)

23 (24)

Mitsubishi standard motor (SF-JR 4P 1.5
kW or lower)

33 (34)

Vector control dedicated motor
SF-V5RU (1500 r/min series)
SF-THY

43 (44)
 Mitsubishi high-efficiency motor SF-HR 
53 (54)
 Mitsubishi constant-torque motor SF-HRCA 
73 (74)

Mitsubishi high-performance energy-saving
motor SF-PR

333 (334)
 IPM motor MM-CF 
8093 (8094)
 IPM motor (other than MM-CF) 
9093 (9094)
 SPM motor 
5 Standard motor
Star
connection
Pr.82(Pr.455) and
Pr.859(Pr.860)
• 0 to 500 A, 9999 (0.01 A)

• 0 to 3600 A, 9999 (0.1 A) 
Pr.90(Pr.458) and
Pr.91(Pr.459)
• 0 to 50 , 9999 (0.001 )

• 0 to 400 m, 9999 (0.01
m)

Pr.92(Pr.460) and
Pr.93(Pr.461)
• 0 to 50 , 9999 (0.001 )

• 0 to 3600 m, 9999 (0.1
m)

Pr.94(Pr.462)
• 0 to 500 , 9999 (0.01 )

• 0 to 100 , 9999 (0.01 ) 

15 Constant-torque motor 
6 Standard motor
Delta
connection

16 Constant-torque motor 

9999
(initial
value)
No second applied motor
