Mitsubishi FR-A800

Parameter List
Parameter list (by function group)
PARAMETERS
153
5
 A: Application parameters
Parameters to set a specific application.
C120 90
Motor constant (R1)
442,
452,
536
C121 91
Motor constant (R2)
442
C122 92
Motor constant (L1)/d-axis inductance
(Ld)
442,
452
C123 93
Motor constant (L2)/q-axis inductance
(Lq)
442,
452
C124 94
Motor constant (X)
442
C125 82
Motor excitation current
442
C126 859
Torque current/Rated PM motor current
442,
452
C130 706
Induced voltage constant (phi f)
452
C131 711
Motor Ld decay ratio
452
C132 712
Motor Lq decay ratio
452
C133 725
Motor protection current level
452
C140 369 
Number of encoder pulses
68,
488,
626
C141 359 
Encoder rotation direction
68,
488,
626
C148 376 
Encoder signal loss detection enable/
disable selection
462
C150 1002
Lq tuning target current adjustment
coefficient
452
C182 717
Starting resistance tuning
compensation
452
C185 721
Starting magnetic pole position
detection pulse width
452
C200 450
Second applied motor
438
C201 453
Second motor capacity
442,
452
C202 454
Number of second motor poles
442,
452
C203 51
Rated second motor current
331,
442,
452
C204 456
Rated second motor voltage
442,
452
C205 457
Rated second motor frequency
442,
452
C206 743
Second motor maximum frequency
452
C207 744
Second motor inertia (integer)
452
C208 745
Second motor inertia (exponent)
452
C210 463
Second motor auto tuning setting/
status
442,
452,
536
C211 574
Second motor online auto tuning
460
C220 458
Second motor constant (R1)
442,
452,
536
C221 459
Second motor constant (R2)
442
C222 460
Second motor constant (L1) / d-axis
inductance (Ld)
442,
452
C223 461
Second motor constant (L2) / q-axis
inductance (Lq)
442,
452
C224 462
Second motor constant (X)
442
C225 455
Second motor excitation current
442
C226 860
Second motor torque current/Rated PM
motor current
442,
452
C230 738
Second motor induced voltage constant
(phi f)
452
C231 739
Second motor Ld decay ratio
452
C232 740
Second motor Lq decay ratio
452
C233 746
Second motor protection current level
452
C282 741
Second starting resistance tuning
compensation
452
Pr.
group
Pr. Name
Refer
to page
C285 742
Second motor magnetic pole detection
pulse width
452
Pr.
group
Pr. Name
Refer
to page
A000 135
Electronic bypass sequence selection
464
A001 136
MC switchover interlock time
464
A002 137
Start waiting time
464
A003 138
Bypass selection at a fault
464
A004 139
Automatic switchover frequency from
inverter to bypass operation
464
A005 159
Automatic switchover frequency range
from bypass to inverter operation
464
A006 248
Self power management selection
470
A007 254
Main circuit power OFF waiting time
470
A100 278
Brake opening frequency
473
A101 279
Brake opening current
473
A102 280
Brake opening current detection time
473
A103 281
Brake operation time at start
473
A104 282
Brake operation frequency
473
A105 283
Brake operation time at stop
473
A106 284
Deceleration detection function
selection
473
A107 285
Overspeed detection frequency
206,
473,
626
A108 639
Brake opening current selection
473
A109 640
Brake operation frequency selection
473
A110 292
Automatic acceleration/deceleration
300,
303,
473
A120 642
Second brake opening frequency
473
A121 643
Second brake opening current
473
A122 644
Second brake opening current
detection time
473
A123 645
Second brake operation time at start
473
A124 646
Second brake operation frequency
473
A125 647
Second brake operation time at stop
473
A126 648
Second deceleration detection function
selection
473
A128 650
Second brake opening current selection
473
A129 651
Second brake operation frequency
selection
473
A130 641
Second brake sequence operation
selection
473
A200 270
Stop-on contact/load torque high-speed
frequency control selection
478,
481
A201 271
High-speed setting maximum current
481
A202 272
Middle-speed setting minimum current
481
A203 273
Current averaging range
481
A204 274
Current averaging filter time constant
481
A205 275
Stop-on contact excitation current low-
speed multiplying factor
478
A206 276
PWM carrier frequency at stop-on
contact
478
A300 592
Traverse function selection
484
A301 593
Maximum amplitude amount
484
A302 594
Amplitude compensation amount
during deceleration
484
A303 595
Amplitude compensation amount
during acceleration
484
A304 596
Amplitude acceleration time
484
A305 597
Amplitude deceleration time
484
A310 1072
DC brake judgment time for swinging
suppression control operation
486
A311 1073
Swinging suppression control
operation selection
486
Pr.
group
Pr. Name
Refer
to page
